26650 2500mAh - High Power LiFePo4 Battery 3.3V ANR26650M1B for A123

Specifications Model: ANR26650M1B

Brand: A123

Nominal Capacity and Voltage: 2500mAh, 3.3V

Maximum continuous discharge: 70A

anr26650m1b 26650 2500mAh - High Power LiFePo4 Battery 3.3V ANR26650M1B for A123 1.  Cell Dimensions(mm): 25.85mm(D)*65.15mm(H)
2.  Cell Weight(g): 76
3.  Cell Capacity(nominal/minimum,Ah): 2.5/2.4
4.  Voltage(nominal,V): 3.3V
5.  Internal impedance(1kHz AC typical,mΩ): 6
6.  HPPC 10 Sec Discharge Pulse Power 50% SOC: 200W
7.  Recommended standard charge method: 1C to 3.6V CCCV, 45 min
8.  Recommended fast charge Method to 80% SOC: 4C to 3.6V CC,12 min
9.  Maximum continuous discharge(A): 70
10. Maximum Pulse discharge(10 seconds,A): 120
11. Cycle life at 10C discharge, 100% DOD: Over 1,000 cycles
12. Operating temperature range: -30°C to +55°C
13. Storage temperature range: -40°C to +60°C
