18650 3100mAh - li-ion battery cell NCR18650A for Panasonic

Specifications Model: NCR18650A

Place of Origin: Japan

Nominal Capacity: 3100mAh

Full Charged Voltage: 4.2V

18650 3100mAh - li-ion battery cell NCR18650A for Panasonic 1. Rated voltage:  3.6V
2. Rated capacity:  2900mAh(Min.cap. in quick charging, standard discharging(1) at 20°C)
3. Nominal capacity:  Min.2950mAh, Typ.3070mAh(In quick charging, standard discharging(2) at 25°C)
4. Standard charging:  4.2V, 590mA, 60mA end(Constant voltage, constant current)(Approval maximum charging voltage by tolerance: 4.25V)
5. Quick charging:  4.2V, 1475mA, 60mA end(Constant voltage, constant current)(Maximum charging voltage: 4.25V)
    Charging method and charger are only those designated.
6. Standard discharging:  580mA(Constant current, 2.5V end)
7. Continuous allowable discharging current:  3540mA(45°C or under)
8. Temperature and humidty range:      0 to 45°C, 45 to 85%RH(in standard charging)
    10 to 45°C, 45 to 85%RH(in quick charging)
    -20 to 60°C, 45 to 85%RH(in standard discharging)
9. Storage Temperature and humidity range:  -20 to 35°C, 45 to 85%RH(within 1 year)
    -20 to 40°C, 45 to 85%RH(within 6 months)
    -20 to 45°C, 45 to 85%RH(within 1 month)
   -20 to 50°C, 45 to 85%RH(within 1 week)
    Note: The capacity recovery rate in the delivery state after storge is assumed to be 80% or more.
10. Volume Energy density:  620.2Wh/l
    Note: This value are alculated by rated capacity, rated voltage and cell volume without shrink tube.
