Expanded Teflon/PTFE Sheets

Get Latest Price

Delivery Time:: 7 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

Product Description Place of Origin: guangdong, China (Mainland) Material: 100% Virgin PTFE Thickness: 0.1~120mm Max Width: 2.7m Color: white, colorful Temperature: -180 - + 260 ℃ Filling: graphite, carbon, bronze Method: skived/molded Density: 2.1-2.3g/cm³ Description China PTFE Teflon Sheet made by en xin long Plastic PTFE Molded sheet is manufactured by molding process with PTFE regular resin and sintering. It is very suitable for seals, lining, diaphragm, spacer guide and bearing pad for bridge. PTFE skived Sheet Roll is manufactured by technique of compacting, sintering, rotary cutting with PTFE granular resin. It has good dielectric performance and non-aging, best anti chemistry corrosion ability and wide applying intension range. Specification

ITEM	Result	Unit
Material	100% Virgin PTFE
Apparent Density	2.10-2.30	g/ cm3
Tensile Strength	22-28	Mpa
Ultimate Elongation	250-300	%
Dielectric Strength	40	KV/mm
Temperature Resist	-180~+260	oC
PTFE Molded Sheet Thickness	1.5mm~120mm
Molded Sheet Length * Width	Min Dimension=150x150mm Max Dimension= 2000x2000mm
PTFE Skived Sheet Thickness	0.1mm~10.0mm
PTFE Skived Sheet Width	Max Width=2700mm

Other size or color can be made based on customers' requirement. Main Features:
1. Heat resistance property. It is able to wok stably between -180°C to +260°C.
2. Excellent non-sticky property. It is easier to remove the resin, oil and other sticky things.
3. Good mechanical property with no distortion and low friction coefficient.
4. Excellent insulation property.
5. Materials like carbon, graphite and glass fiber can be filled.
6. Virgin and recycled materials are available.

Company Information Shenzhen EN Xin LONG Special engineering plastics PlasticCo., Ltd. is a professional manufacturer specializing in engineering plastic and high polymer material. It is located in the beautiful shenzhen dapeng, guangdong Province. It’s a company combining researching and manufacturing of PTFE/ UHMW-PE/ Nylon products. Our main products include PTFE molded products (all kinds of sheets, rods, tubes), PTFE extruded products (all kinds of tubes, rods), molding parts processed according to drawings; UHMW-PE molded products (all kinds of sheets), UHMW-PE extruded products (all kinds of rods, tubes), UHMW-PE rollers, UHMW-PE molding parts processed according to drawings; and nylon molding parts, rubber products processed according to customers’ drawings. Our products are widely used in petroleum, chemical industry, light industry, military, machinery, electricity, food, medicine,aerospace, automobile, textile, mining, bridges, electrical and electronics,instrument,transportation,building materials etc.Our products are widely used in all areas of people's lives. In addition to domestic sales, we also export to South Korea, India, Iran, Italy, Canada, Spain and other countries. Our company processes various advanced equipments and testing devices. Our large hydraulic cylinders are unique among domestic PTFE manufacturers. We also have perfect producing facilities such as peeling machines, large-scale high-temperature sintering furnaces and extruding machines. In addition, we have first-rate testing equipments like tensile testing machine, abrasion machine, high pressure electrostatic tester, resistance tester and so on. With the help of the advanced equipments and excellent staff, we own good reputation in high quality, competitive price, timely delivery and good after-sales service. We will continue to focus on improving our research and creation capability. Welcome to visit our company for business cooperation!
