P10 Outdoor Hight Brightness Waterproof LED Full Color Video Wall

P10 Outdoor Hight Brightness Waterproof LED Full Color Video Wall Parameters

Module	NO.	Item	Parameter
	1	Module Model	SH-P10(Outdoor)
	2	Pixel pitch	10mm
	3	Module dimension	320mm*160mm
	4	Module density	10,000pixel/sqm
	5	Module resolution	32*16dots
	6	LED chips	Nationstar
	7	LED encapsulation	SMD 3in1(3535)
	8	Pixel configuration	1R1G1B
Cabinet	1	Dimension	960*960*100mm
	2	Physical resolution	96*96dots
	3	Module quantity	18PCS
	4	Weight	28kg/PCS
	5	Material	Aluminum
	6	Driving method	Constant current 1/2 scan
	7	Brightness	≥6000nits
	8	Max power consumption	900W/SQM
	9	Average consumption	350W/SQM
	10	Frame frequency	60Hz
	11	Refresh frequency	>1200HZ
	12	Gray level	16384~65536
	13	IP grade	IP65
	14	Input Voltage	AC100-120V  AC200-240V
	15	Power supply	5V/60A   3PCS
	16	Viewing angle(H/V)	120°/ 120°
	17	viewing distance	5m-200m
	18	Working environment	Temperature: -20°C~ 60°C
			Humidity:10%~90%RH
	19	Control system	Synchronous or Asynchronous Control system
	20	Display function	Videos ,animation, picture,text,etc.
	21	Certificate	CE Certification (SGS)

Product   Function & Advantage   1.Cabinets can be spliced with no crack.
2.P5/P6/P6.67/P8/P10/P16 is optional for you.
3. SMD three-in-one technology with high brightness makes the display have a ultra-wide view & vivid image when in use.
4. Work normally without air conditioning for low powe consumption.
5.Suitable for Outdoor application,big square,shopping malls,railway stations,Airport,stage renting,etc.
  Our service 1.Your inquiry about our products or the price will be replied within 24 hours!
2.We provide 2 years for warranty and lifelong maintaining ,you will appreciate our warm after-sale service.
3.We will delivery goods as you demand ,you can choose the cheaper and more convenient way!
4.We can provide mature customised solution for you. Company Information                                                               Company   Profile       VisionLED was established in 2003, we are a professional LED media/video display exporter and manufacturer. since its establishment, we are always following the new changes of LED industry. So far, our LED products are sold widely around the world ,VisionLED also has got good reputation from different users, our products are mainly supplied for international market, so offering quality products, competitive price, patient and fast technology support are the root of the our enterprise survival in the big market. At any time,we are the best one of your reliable choice.                                                                        Our Main Products                                               Indoor LED Display screen                        Outdoor LED Display Screen                                          Flexible display                                          LED Cross/ customized sign                                                         Contact              Shenzhen Shihan Technology Co., Ltd VisionLED Optoelectronic Technology HK Co., Ltd Address: 4th Floor, No.4 Building, Hongfa Hi-tech Park, Tangtou, Shiyan Town, Bao'an District, Shenzhen, China 518108 Tel: 0086-755-26009386,  Fax: 0086-755-26009157                                     Sales: Sharon                                                      Email: sales03[at]visionled.cn                                     Skype: sharon.tyan                                              WhatsApp: 0086-13515970927                                     Facebook: @sharon9tyan                                     Twitter: @sharon9tyan                                                            Recommend  Products  (NEW)

P3 HD Indoor

P2.5 HD Indoor

Flexible Indoor

Packaging & Shipping Packing: Anti-shaking wooden cabinet /Air flight case/strong carton Shipping port: Shenzhen. China Shipping ways and freights are quoted according to your requests Delivery time:5-15 working days Payment Term: T/T, Trade Assurance,Western Union,Moneygram etc. Long working life:In the Maintenance period, free of all maintenance charges. After Maintenance period, only charge the material costs fees.   Certifications   Working Diagram    P10 Outdoor Hight Brightness Waterproof LED Full Color Video Wall
