5.8G mimo solid parabolic dish antenna with 35dbi high gain

Specifications 1,Wlan dish antenna

2,Durable,waterproof,corrosion resistance

3,Far distance delivery

4,Good appearance

5,OEM & ODM

5.8G mimo dish antenna with 35dbi high gain     Specification :

ELECTRICAL
MODEL	GA-PWD5158-35x2
Frequency Range	5150-5850-MHz
Bandwidth	700-MHz
Gain	35x2dBi
Beamwidth	H:3° E:3°
F/B ratio	≥40-dB
VSWR	≤1.5
Polarization	Vertical & Horizontal
Max power	100 -W
Nominal Impedance	50 -Ω
Lightning Protection	DC Ground
MECHANICAL
Connector­­­	2xN female
Antenna Dimension	1.2-M
Weight	29-Kg
Rated Wind Velocity	60-m/s
Diameter of the Pole	90~150

     Installation Instruction :       Introduction :   Gisantone has a top researching team, advanced testing equipment and powerful technical strength. We research, produce and sell VHF, UHF, CDMA, GSM, WCDMA, CDMA2000, TD-SCDMA, MIMO , WIFI, WLAN, WIMAX , 5.1G-5.8GHz , 4GHz LTE , directly repeater station, indoor coverage antennae, prettify antennae, wireless public telephone, various communicational antennae of any frequency from 88MHz to 6GHz . Providing OEM & ODM serivces . If you have any needs, welcome to contact . We looking forward to hearing from any of your news .     Gisantone View:            Process of Manufacture :           Certification :
