Sumitomo Type 81C/71C/Z1C Fiber Optic Fusion Splicer Kit With FC-6S cleaver

 Sumitomo Type 81C/71C/Z1C  Fiber Optic Fusion Splicer Kit With FC-6S cleaver           IN STOCK! HOT! Contact information Mobile:0086-13823128817 Tel:0086-755-36934393 Fax: 0086-755-33503470 Skype:kitty.hsv           Accessaries Include:   a) TYPE-81C main unit, b) AC adapter and Charger Cable, power supply module: ADC-1430 c)  Battery module: bu-11 d) Cooling Tray, e) Carrying case  with worktable: CC-81 f) Precision Fiber Optic Cleaver g) AC Power Cord, h) Operation CD manual , i)  USB cable, j) Quick reference guide K) Hand strap      Speicifications:

Product name		TYPE-81C
Optical fiber requirements	Material	Silica glass
	Profile types	SMF (ITU-T G.652), MMF (ITU-T G.651), DSF (ITU-T G.653), NZDSF (ITU-T G.655), BIF (ITU-T G.657), EDF
	Fiber diameter	Cladding diameter: 80μm~150μm, Coating diameter: 100μm~1,000μm
	Applicable fiber or cable size	up to ø1,000μm		Drop cable (2.0×3.1mm) Indoor cable (2.0×2.0mm)
	Cleave length	5~16mm		10mm
Standard performance	Splice loss (typical) *1	SMF: 0.02dB, MMF: 0.01dB, DSF: 0.04dB, NZDSF: 0.04dB
	Splicing cycle time (typical)	7sec. (Quick mode), 7.5sec. (SMF standard mode), 8sec. (Auto mode)
	Heating cycle time (typical)	28sec.
	Splice & Heat cycles *2	Approx.200
	Fiber view & magnification	Two CMOS cameras observation 320X (zoom:700X) for X or Y single axis view, 88X for both X & Y dual axis view
Programs	Splicing programs	Max.300
	Heating programs	Max.100
Functions	Loss estimation	Provided
	Splice image capture/ Splice data storage	64 images/10,000 splice data
	Proof test	1.96N (200gf)
	Attenuation splicing	0.1dB to 15dB in 0.1dB increments
	Universal clamps for 250μm, 900μm tight & loose buffer fiber	Provided
	Reversible coating clamps	Provided
	Dual automatic independent heaters	Provided (US patent 7,412,146)
	User-selectable heater clamp operation	Provided
	Onboard user training video	Provided
	Automatic arc calibration	Automatically compensates for environmental condition changes
	Arc test	Provided
	Display of remaining Splice & Heat cycles	Provided (Battery mode)
	Remote interactive maintenance	Provided
Size/Weight	Size	120(W)×154(D)×130(H)mm (without anti-shock rubber)
	Weight	1.8kg (without battery), 2.1kg (with battery)
	Monitor	4.1" touch screen color LCD display
Terminals	DC output	DC12V (for JR-6)
	USB port	USB 2.0 (mini-Btype)
	Storage media	SD/SDHC memory card
Power supply	AC input	100~240V, 50/60Hz (ADC-1430)
	DC input	10~15V
	Battery module	Li-ion 11.1V, 4,600mAh (BU-11)
Operating condition	Altitude:0~6,000m, Temperature: -10~+50°C, Humidity: 0~95% (non-condensing), Wind velocity up to 15m/s
Storage condition	Temperature: -40~+80°C, Humidity: 0~95% (non-condensing), Battery: -20~+30°C (long term)
Electrode life	3,000 arc discharges *3
