High Quality Fiber Optic Cable Protection Sleeve with best price

Specifications Splice Protector ,Protection Sleeve,Fiber Optic Cable Protection Sleeve,High Quality Fiber Optic Cable Protection Sleeve,Fiber

high quality Heat Shrinkable Fiber Optic Splice Protector
high quality production cycle time: 2 days
according to your needs   high quality Heat Shrinkable Fiber Optic Splice Protector            Features          Consist of cross-linked polyolefin, hot fusion tubing and stainless reinforced steel rod          Keep optical transmission performance of optical fiber           Provide safe protection to optical fiber splicing           Easily use and avoid any damage to the optical fiber during installation          Clear sleeve makes it easy to detect splice before shrinkage          Sealing structure provides good performance to the splicing in the environment with temperature and humidity   Operating Temperature : -45 – 100 °C  Shrinking Temperature Range: 90 - 110 °C Packing : 100 Pcs/Bag     Technical Data :

Properties	Test Method	Typical Data
Tensile Strength(MPa)	ASTM D 2671	18
Ultimate Elongation(%)	ASTM D 2671	700
Density(g/cm2)	ISO R1183D	0.94
Dielectric Strength (KV/mm)	IEC 243	20
Dielectric Constant	IEC 243	2.5
Longitudinal Change(%)	ASTM D 2671	+5

      Dimension :

PN	Steel Rod		Fusion Tube		Heat Shrink Tube	Device
	O.D.	Length	I.D.	Length	Length	O.D. (after shrink)
	(mm)	(mm)	(mm)	(mm)	(mm)	(mm)
APD-450501	0.5*45mm	45±1	0.5±0.1	45±1	45±1	1.6±0.1
APD-450801	0.8*45mm	45±1	1.1±0.1	45±1	45±1	2.0±0.1
APD-451001	1.0*45mm	45±1	1.1±0.1	45±1	45±1	2.3±0.1
APD-451201	1.2*45mm	45±1	1.3±0.1	45±1	45±1	2.5±0.1
