OSA Optical Spectrum Analyzer EXFO FTB-5240S

EXFO FTB-200/500-5240S/BP optical spectrum analyzer OSA  / DWDM tester    OSA Optical Spectrum Analyzer   EXFO FTB-5240S       contact information Nancy Liu Viber / Tel : +86 15118174252 skype:   nancy.hsv         Platform compatibility
FTB-200 Platform
FTB-400 Platform FTB-500 Platform         Highly accurate, easy-to-use OSAs for current and next-generation networks KEY FEATURES In-band OSNR measurement for 40 Gbit/s and ROADM deployments with the PROS-OSNR breakthrough approach One-button operation for easy setup and automatic measurement Truly portable spectral characterization for DWDM network commissioning Over 90 dB dynamic range per scan Flexibility to analyze WDM, EDFA, drift, spectral transmittance and DFB laser High-power option, ideal for multiservice operators and CATV operators         NIMBLE OSA MEETS SUPERTECH PLATFORMS The FTB-5240S OSA test module, housed in either the FTB-500 Platform or the FTB-200 Compact Platform, is purpose-built for fast and accurate dense wavelength-division multiplexing (DWDM) network commissioning and high-speed networking up to 40 Gbit/s. Housing the FTB-5240S in the FTB-200 platform makes it the smallest, high-performance, portable solution for spectral characterization of next-generation networks on the market. When equipped with in-band OSNR measurement capabilities, this versatile OSA can also be combined with the FTB-8140 Transport Blazer test module to create a unique test solution for commissioning reconfigurable optical add/drop multiplexers (ROADMs), packet optical transport platforms (POT-Ps) and 40 Gbit/s systems.       Measurement Characteristics
Multiple scans, changing the polarization state between them and using the data to determine the OSNR in-band for each channel
For new modulation schemes, such as non-return-to-zero (NRZ), duo binary, differential phase-shift keying (DPSK), quadrature phase
shift keying (QPSK), which present large line widths and often display multiple peaks, in-depth analysis ensures the correct
identification and signal measurement of each carrier
Simultaneous testing of the physical and transport or datacom layers when combined with other EXFO modules in the FTB-500 Platform             High-Power Option
With today’s high-power signals making their way into the DWDM space, it is critical to have an OSA that can measure them accurately without risking  damaging  your  test  equipment.        The  FTB-5240S  matches  this need,  offering  a  high-power  option  (FTB-5240S-HPW)  allowing  up  to  +23 dBm input power per channel.   The option is available with or without  the in-band capability.        FTB-200             FTB-500                      Our Main Products   1. FUSION SPLICER: Comway C10; Sumitomo (T-81C); Fujikura (FSM-80S/70S/70R); Fitel S178A; INNO IFS 10 2.OTDR: EXFO (FTB-1/AXS-110/AXS-100/ FTB-200/FTB-500); JDSU (MTS-2000/4000/6000/8000); YOKOGAWA (AQ1200/AQ7275) 3. POWER METER (PPM-350C, FPM-300, HSV-300P); LIGHT SOURCE (FLS-300, HSV-300L); VFL (FLS-241, HSV-321); Multi Loss tester (FOT-930, FOT-302) 4. Anritsu site master S331D, S331L, S331E, S332E. 5. Fiber cleaver (CT-30A/CT-30/CT-05/FC-6S), adapter, battery, electrode, connector, fiber tool kits 6. Fiber cable, patch cord, adapter, closure, pigtail, optical switch, patch panel, etc.. 7.Maintainance and repair, calibration service for the EXFO, JDSU, Sumitomo, Fujikura, Anritsu
