EXFO OTDR & EXFO MAX-715B-M1 OTDR PRICE

EXFO OTDR & EXFO MAX-715B-M1 OTDR PRICE   Product Description
The MAX-700B series is the first tablet-inspired OTDR line that is handy, lightweight and rugged enough for any outside plant environment. With a 7-inch, outdoor-enhanced touchscreen –the most efficient handheld display in the industry– it delivers an unprecedented user experience. Its intuitive Windows-like GUI ensures a fast learning curve. Plus, its new and improved OTDR 2.0 environment offers icon-based functions, instant boot-up, automatic macrobend finders as well as improved auto and real-time modes.
The Max-700B series is a line of genuine high-performance OTDRs from the world’s leading manufacturer. It delivers EXFO’s tried and true OTDR quality and accuracy along with the best optical performance for right-first-time results, every time.
The amazing 12-hour battery life will never let a technician down, and the plug-and-play hardware options, like the VFL, power meter and USB tools, make every technician’s job easier.
Most importantly, the Max-700B series is finally bringing the iOLM, an intelligent OTDR-based application, to the handheld market. This advanced software turns even the most complex trace analysis into a simple, one-touch task.
Ultimately, the Max-700B series is small enough to fit in your hand and big enough to fit all your needs!
THE ENTRY-LEVEL SOLUTION DESIGNED FOR ALL YOUR TESTING NEEDS
The MAX-730B OTDR/iOLM is optimized to test through optical splitters up to 1x128, ensuring complete end-to-end FTTH characterization.The 1625-nm, out-of-band, live testing port enables the efficient troubleshooting of active networks without affecting the signal of other clients. Plus, the high dynamic range makes it suitable for Metro point-to-point testing.
Other models available :
MAX-715B Short Access and FTTx Last-Mile installation and troubleshooting (30 dB)
MAX-720B Access for any short network construction (36 dB)   Applications
FTTx/MDU test challenges within PON networks
Access network testing (P2P)
Metro links testing (P2P)
Live fiber troubleshooting
Key Features
Handy, lightweight, powerful, tablet-inspired design
7-inch, outdoor-enhanced touchscreen – the biggest in the handheld industry
12-hour autonomy
Dead zones: EDZ 0.8 m, ADZ 3.5 m
Dynamic range: 39/37/37 dB
Rugged design built for outside plant
iOLM-ready: intelligent and dynamic application that turns complex OTDR trace analysis into a one-touch task

Models	Description
MAX-710B-XX	MAX-710B, Last Mile SM OTDR 1310/1550 nm, 29/28 dB (9/125 µm) Macrobend Finder and Summary Screen Software Features - Display: 7" Color Touchscreen TFT - Memory: 2GB Internal - 2x USB 2.0 Interfaces - RJ-45 Built-In Interface [Note] ! iOLM-ready (APC only)
MAX-715B-M2-XX	MAX-715B, Last Mile SM OTDR Port 1 : 1310/1550 nm, 30/28 dB (9/125 µm) Port 2 : Filtered 1625 nm, 28 dB (9/125 µm) Macrobend Finder and Summary Screen Software Features - Display: 7" Color Touchscreen TFT - Memory: 2GB Internal - 2x USB 2.0 Interfaces - RJ-45 Built-In Interface [Note] ! iOLM-ready (APC only)
MAX-715B-M3-XX	MAX-715B, Last Mile SM OTDR 1310/1550/1625 nm, 30/28/28 dB (9/125 µm) Macrobend Finder and Summary Screen Software Features - Display: 7" Color Touchscreen TFT - Memory: 2GB Internal - 2x USB 2.0 Interfaces - RJ-45 Built-In Interface [Note] ! iOLM-ready (APC only)
MAX-720B-M1-XX	MAX-720B, Access SM OTDR 1310/1550 nm, 36/34 dB (9/125 µm) Macrobend Finder and Summary Screen Software Features - Display: 7" Color Touchscreen TFT - Memory: 2GB Internal - 2x USB 2.0 Interfaces - RJ-45 Built-In Interface [Note] ! iOLM-ready (APC only)
MAX-730B-M1-XX	MAX-730B, FTTx/PON SM OTDR 1310/1550 nm, 39/37 dB (9/125 µm) Macrobend Finder and Summary Screen Software Features - Display: 7" Color Touchscreen TFT - Memory: 2GB Internal - 2x USB 2.0 Interfaces - RJ-45 Built-In Interface [Note] ! iOLM-ready (APC only)
MAX-730B-M2-XX	MAX-730B, FTTx/PON SM OTDR Port 1 : 1310/1550 nm, 39/37 dB (9/125 µm) Port 2 : Filtered 1625 nm, 37 dB (9/125 µm) Macrobend Finder and Summary Screen Software Features - Display: 7" Color Touchscreen TFT - Memory: 2GB Internal - 2x USB 2.0 Interfaces - RJ-45 Built-In Interface [Note] ! iOLM-ready (APC only)
MAX-730B-M3-XX	MAX-730B, FTTx/PON SM OTDR 1310/1550/1625 nm, 39/37/37 dB (9/125 µm) Macrobend Finder and Summary Screen Software Features - Display: 7" Color Touchscreen TFT - Memory: 2GB Internal - 2x USB 2.0 Interfaces - RJ-45 Built-In Interface [Note] ! iOLM-ready (APC only)
Options	Description
PM2X-XX	Power Meter ONLY (GeX detector) With FOA-xx: Connector Adapter must be specified**                            **Connector choice may affect pricing.
VPM2X-XX	VFL + Power Meter - Visual Fault Locator (650 nm)      With 2.5 mm Universal adapter - Power Meter (GeX detector)      With FOA-xx: Connector Adapter must be specified**                              **Connector choice may affect pricing.
RF	Built-in Wi-Fi and Bluetooth Capability
	[Factory UPGRADE order code]: MAX-700B-RF-UPG - To upgrade a unit, after the original purchase/delivery,      that REQUIRES TO BE RETURNED to one of EXFO's service center. - RMA is required before returning a unit.
Probe Options	Description
FP410B-XX**	Digital Video Inspection Probe - NO Automated PASS-FAIL analysis - Triple Magnification - ConnectorMax2 Software [APC or UPC Bulkhead and Patchcord tips] **(-XX): APC or UPC must be specified        Refer to FIP-400B product page for details. [Also including] - Software (on CD) - Instruction Manual (Soft Copy) - Certificate of Compliance (Hard Copy) - Compartmented plastic case for tips - GP-2175: Protective cap & cord assembly - GP-10-094: Soft pouch
FP420B-XX**	Analysis Digital Video Inspection Probe - Automated PASS-FAIL analysis - Triple Magnification - Auto Center - ConnectorMax2 Software [Bulkhead and Patchcord tips] **(-XX): APC or UPC must be specified        Refer to FIP-400B product page for details. [Also including] - Software (on CD) - Instruction Manual (Soft Copy) - Certificate of Compliance (Hard Copy) - Compartmented plastic case for tips - GP-2175: Protective cap & cord assembly - GP-10-094: Soft pouch
FP430B-XX**	Automated Analysis Digital Video Inspection Probe - Automated Focus - Automated PASS-FAIL analysis - Triple Magnification - Auto Center - ConnectorMax2 Software [Bulkhead and Patchcord tips] **(-XX): APC or UPC must be specified        Refer to FIP-400B product page for details. [Also including] - Software (on CD) - Instruction Manual (Soft Copy) - Certificate of Compliance (Hard Copy) - Compartmented plastic case for tips - GP-2175: Protective cap & cord assembly - GP-10-094: Soft pouch
