EXFO FTB-1v2-720c OTDR price JDSU OTDR

FTB-1v2-720C Exfo SM OTDR  IN STOCK !!         Contact information Nancy Liu Skype:  nancy.hsv WhatsApp: +8615118174252                Description:      The FTB-1 version 2, available in a standard (FTB-1 V2) or Pro (FTB-1 Pro) model, is a
portable system designed for fast and powerful optical, Ethernet, time-division multiplexing
(TDM) and multiservice applications.
  Includes : - Instruction Manual (Soft Copy)
(Mainframe) - Quick Reference Guide (Hard copy)
- GP-2253: Li-Ion smart battery (qty:1)
- GP-2233: 90W, AC Adapter with power cord
- GP-2232: Hand strap
- GP-2151: Hook strap
- GP-2235: Stylus (qty:1)
  "Single-slot capacity Modular mainframe
Windows 8.1 Pro OS, QUAD Core CPU
- Multi-touch widescreen, color, 1280 x 800 TFT, 203 mm (8 in)
- RAM: 4 GB Internal memory
- Interfaces:
> RJ-45 LAN 10/100/1000 Mbit/s
> USB 2.0 ports (qty:2)
> USB 3.0 port
> 3.5 mm audio jack (speaker/mic)



Mainframe	Dual-core processor/4 GB RAM/Windows Embedded 8 Standard
Display	Multitouch, wide-screen, color, 1280 x 800 TFT 203 mm (8 in)
Interfaces	RJ45 LAN 10/100/1000 Mbit/s Two USB 2.0 ports One USB 3.0 port Micro SD card slot 3.5 mm headset/microphone port
Storage	64 GB internal memory (flash)
Battery	Rechargeable Li-ion smart battery
Power supply	AC/DC adapter, input: 100 – 240 V; 50/60 Hz; 2.5 A max, output: 24 V; 3.75 A
Size (H x W x D)	With single-depth module 210 mm x 254 mm x 66 mm (8 ¼ in x 10 in x 2 5 / 8 in) With double-depth module 210 mm x 254 mm x 96 mm (8 ¼ in x 10 in x 3 13 / 16 in)
Weight (with battery)	1.5 kg (3.3 lb)
Temperature	Operation 0 °C to 50 °C (32 °F to 122 °F) Storage –40 °C to 70 °C (–40 °F to 158 °F) b
Relative humidity	0 % to 95 % non-condensing



Models	Description
FTB-720C-SM1-XX	SM OTDR Module  1310/1550 nm, 36/34 dB (9/125 µm)
FTB-720C-SM2-XX	SM OTDR Module  Port 1: 1310/1550 nm, 36/35 dB (9/125 µm)  Port 2: Filtered 1625 nm, 35 dB (9/125 µm) for live fiber testing
FTB-720C-Q1-XX	MM OTDR Module  Port 1: 850/1300 nm, 27/29 dB  (50/125 & 62.5/125 µm)  Port 2: SM Hardware ready and field upgradable to 1310/1550 nm
FTB-720C-Q1-QUAD-XX	QUAD OTDR Module  Port 1: 850/1300 nm, 27/29 dB  (50/125 & 62.5/125 µm)  Port 2: 1310/1550 nm 36/35 dB (9/125 µm)
FTB-730C-SM1-XX	SM OTDR Module  1310/1550 nm, 39/38 dB (9/125 µm)
FTB-730C-SM2-XX	SM OTDR Module  Port 1: 1310/1550 nm, 39/38 dB (9/125 µm)  Port 2: Filtered 1625 nm, 39 dB (9/125 µm) for live fiber testing
FTB-730C-SM3-XX	SM OTDR Module  1310/1550/1625 nm, 39/38/39 dB (9/125 µm)
FTB-730C-SM8-XX	SM OTDR Module  Port 1: 1310/1550 nm, 39/38 dB (9/125 µm)  Port 2: Filtered 1650 nm, 39 dB (9/125 µm) for live fiber testing
FTB-730C-SM6-XX	SM OTDR Module  Filtered 1625 nm, 39 dB (9/125 µm) for live fiber testing
FTB-730C-SM7-XX	SM OTDR Module  Filtered 1650 nm, 39 dB (9/125 µm) for live fiber testing
FTB-735C-SM1-XX	SM OTDR Module  1310/1550 nm, 42/41 dB (9/125 µm)
FTB-735C-SM2-XX	SM OTDR Module  Port 1: 1310/1550 nm, 42/41 dB (9/125 µm)  Port 2: Filtered 1625 nm, 41 dB (9/125 µm) for live fiber testing
FTB-735C-SM3-XX	SM OTDR Module  1310/1550/1625 nm, 42/41/41 dB (9/125 µm)
FTB-735C-SM4-XX	SM OTDR Module  1310/1490/1550 nm, 42/41/41 dB (9/125 µm)
FTB-750C-SM1	SM OTDR Module  1310/1550 nm, 46/46 dB (9/125 µm)
FTB-750C-SM3	SM OTDR Module  1310/1550/1625 nm, 45/45/45 dB (9/125 µm)
