optic fiber fusion splicer fitel s178a fusion splicer
- Delivery Time:
- 3 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Japan |
|---|
in stock brand new
original package
in promotion
optic fiber fusion splicer fitel s178a fusion splicer Be free to contact kitty if any questions, You can also log onto www.hontek.net for more information! kitty skype: kitty.hsv
Specifications | |
Applicable Fibers | SM, MM, DSF, NZD, EDF, BIF/UBIF (Bend insensitive fiber) |
Cladding Diameter | 80~150 μm |
Coating Diameter | 160~900 μm |
Fibers Cleave Length | 5~16 mm |
Average Splice Loss | SM: 0.02 dB, MM: 0.01 dB, DSF: 0.04 dB, NZD: 0.04 dB |
Splice Time | 7 seconds (semi-auto mode) 9 seconds (regular mode) |
Heat Time | 25 seconds (40mm Sleeve, 60mm Sleeve) (Pre-heat mode) 31 seconds (40mm Sleeve, 60mm Sleeve) (regular mode) |
Splice Programs | Max. 150 |
Automatic Splicing Selection | SM: SM, DSF, NZD, BIF/UBIF, MM: MM |
Heat Programs | Max. 18 |
Automatic Heating Start | Available |
Applicable Sleeves | 20/40/60 mm |
Fiber Holding | Tight holder (Loose tube applicable) or Fiber Holder System |
Tension Test | 1.96N |
Fiber Image Magnification | 304X, 608X |
Splice Memory | Max. 2,000 |
Image capture Capacity | Last 100 images to be automatically captured + Up to 24 images to be stored permanently |
Dimension | 127W × 199D × 105H mm (not including shock absorber) 159W × 231D × 130H mm (including shock absorber) |
Weight | 1.9 kg (without battery) 2.3 kg (with two batteries) |
Monitor | 3.5” color LCD monitor |
Data Output | USB ver.2.0 mini |
Diaplaying Language | 20 languages (e.g. English, Spanish, Japanese, Chinese) |
Battery Capacity | Typical 80 splice/heat cycles with single battery Typical 200 splice/heat cycles with 2 batteries |
Altitude | 5,000 mh |
Operating Temperature | -10 to +50 °C (without excessive humidity) |
Storage Temperature | -40 to +60 °C (without excessive humidity) |
Power Source | AC Input 100 to 240 V (50/60 Hz), DC Input 11 to 17 V |
