High Precision Fiber Cleave sumitomo FC-6S

High Precision Fiber Cleave  sumitomo FC-6S   Contact information Mobile:0086-13823128817 Tel:0086-755-36934393 Fax: 0086-755-33503470 Skype:kitty.hsv   The Sumitomo FC-6S high precision cleaver is designed for field use alongside the Sumitomo splicing units.By using a rotating blade for multiple scoring positions enables a blade life of 36, 000 cleaves with a cleave angle better than 0. 5 degrees. The unit is constructed to be robust and field serviceable and has options such as tripod mount to enable secure platform mounting. The FC-6S is the latest Sumitomo cleaver. Integral to the unit is a cleave length scale which helps facilitate exact lengths during cleaving.       Specifications

Model		FC-6M	FC-6M-C	FC-6S	FC-6S-C
Applicable Fiber	Fiber diameter	125um
	Fiber count / size	Single fiber (0.25 & 0.9mm) and up to 12-fiber ribbon		Single fiber (0.25 & 0.9mm)
Cleave length		10mm		9 ~16mm (0.25) 10~16mm (0.9 )
Typical cleave angle		0.5°
Dimensions / Weight		63(W) x 76(D) x 63(H)mm / 430g (FC-6M/FC-6S) 100(W) x 81(D) x 63(H)mm / 480g (FC-6M-C/FC-6S-C)
Blade life		36,000fibers (1,000fibers x 12 edge positions x 3-step edge height)
Option		Adapter for single fiber : AP-FC6M (Standard installation with the FC-6S/FC-6S-C) Offcut collector : CU-FC6 (Standard installation with the FC-6M-C/FC-6S-C) Blade replacement : FCP-20BL
