Soway auto on off float switch

 product name:   Water Level Controller Float Switch    1.   INTRODUCTION Magnetic float level switch principle is the float which link to rod equipped with a constant magnetic field, because of the liquid level rise or fall, make the float internal generated magnetic field, thus triggered  the reed switch which inner the rod wroking. Widely used in liquid level measurement, liquid level alarm and level security control field.   2.  FEATURES 2.1 No standby power requirement 2.2 Customer can defined activated range and connection 2.3 Enclosure material: stainless steel 304 or 316 2.4 High stability, high reliability, high consistency   3. APPLICATIONS Level control, level measurement Home appliance level detection Water cooler, coffee machine, water dispenser, humidifier, etc Container level detection   4. SPECIFICATION

Electrical Parameters
Model	1	2	3
Switched Power(max)	10W	70W	5W
Switched Voltage(max)(DC)	200V	200V	175V
Switched Voltage(max)(AC)	140 V	250V	125V
Switched Current(max)(DC)	500mA	1000mA	400mA
Switched Current(max)(AC)	500mA	1000mA	280mA
Breakdown Voltage(min)	250V DC	580V DC	200V DC
Carry Current(max)	1.0A	2.25A	0.5A
Contact  Resistance (min)	200mΩ	200mΩ	200mΩ
Insulation Resistance (min)	106MΩ	106MΩ	106MΩ
Operating Temperature	-40°C-+80°C	-40°C-+80°C	-40°C-+80°C

    ENTIRE FILM Q: What payment method your company accepts? A: We accept T/T (Bank Transfer), L/C, Western Union and Paypal. If any other payment method is more convenient to you, please tell us by including a note while making payment.   DIREDT SELLING PRICE Q: Can you do drop shipping? A: Yes, we can help you ship the goods to any address you want. We will not put any catalogue or any document with our company info in it if you requested.   HIGH QUALITY QUALITY Q: How long for the production time? A: Normally in stock, or 7~10days depends on order quantity.   PACKING SPECIFICATION Q: You said we can use our own logo? What's the MOQ if we wanna do this? A: Yes, 100pcs MOQ   GOOD FAITH SERVICE Q:How to contact you guys? A:Skype ID:jack-soway B:Contact us by e-mail
