IC/RFID card reader/writer CRT-571

  IC/RFID card reader/writer CRT-571 Features:    *Stacker: Equip with removable stacker. As well, it can issue cards independently without the removable stacker.   *Removable stacker with lock: The cards can be locked in the removable stacker.   *Removable stacker can be locked to the machine body to prevent stolen.   *Concave style of card thickness adjustment.   *Customization Options: PC/SC   *Multi-units communication: Support Max.16 sets of CRT-571.   *Compact size and low cost: One of the most compact card issuing machines with IC/RFID card module      Applications:    *Automatic card vending machine   *Highway card issuing system   *Card batch initialization   *Parking system     Automatic card vending machine / Highway card vending machine CRT-571   Specifications:


Model	CRT-571
Features	Plastic frame module, IC/RFID card read/write
	Dispense/capture/accept card
	Removable stacker options
	Very compact & robust
Application	Card parking system
	Card issuing machine
	Card vending machine
Specification
Card standard	IC Card: ISO7816 RFID Card: ISO14443 Type A/B
Card Thickness	0.4-1.0mm
Stacker Capability	120pcs(0.76mm standard card)
Removable Stacker	250pcs/500pcs
Card pre-empty detection	7-50pcs +/- 2pcs (0.76mm standard card)
Communication	RS-232 /USB
Power supply	DC 24V+/-5%
Temperature/Humidity	Operation: 0-50°C/0-90%RH(Non-condensing) Storage: -10-75°C/0-90%RH(Non-condensing)
Dimension	240x98x165mm
Weight	Approx. 2.5kg
