mc55 mc56 gsm gprs wireless module

Specifications mc55 mc56 gsm gprs module

1.in stock 1000pcs

2.GSM/GPRS module

 mc55 mc56 gsm gprs module                                              Features:
. The smallest double tri-ban modules
. Tri 900, 1800 and 1900 MHz(MC55)
. Tri 850, 1800 and 1900(MC56)
. GPRS (class 10), PBCCH support.
. Dimension: 35 x 32.5 x 2.95 mm Detail introduce:
.  Voltage: 3.3V ~ 4.8V
.  Output power: 2W (GSM850/900MHz Class 4)
                 1W (DCS1800/1900MHz Class 1)
.  SIM card connector type: External
.  Antenna: RF Cable connect with external Antenna
.  Temp range: Normal Temp: -20 C to +70 C
               Store Temp: -40 C to +85 C
.  Power consumption :
     Speech mode(average): 260mA
     Sleep Mode: 3.0mA (Max)
     Power down: 50microampere (Max)   GPRS Class 10(average): 450mA .  Specification for voice:
    Triple-rate code for HR,FR and EFR
    Adaptive multi-rate AMR
    Basic hands-free operation
    Echo cancellation
    Noise reduction .  Specification for SMS:
    Point-to-point MO and MT
    SMS cell broadcast
    Text and PDU mode .  Dimension :35 x 32.5 x 2.95mm
.  Communication interface: RS232
.  SIM card interface:3V/1.8V   . Specification for GPRS data transmission
GPRS class 10: max. 86kpbs(DL)
Mobile station class B
PBCCH support
