Super Thin Card iBeacon

--Super Thin Card iBeacon-- Product Description   The BLE Beacon Card C7 is designed based on the Low Energy Bluetooth 4.0 technology, the shape of Beacon Card C7 looks a bank/RFID card but it is waterproof and it has packed a Lithium polymer battery. Beacon Card C7 broadcasts the data at regular and adjustable intervals according to Apple’ standard iBeacon protocol, it can be heard and interpreted by iOS and Android BLE-enabled devices that are equipped with many mobile apps. It widely used for the access control, trade shows, conferences, events and so on.   Specification

Item	Value	Remarks
Case Color	white	Other colors can be customized
Battery Model	Lithium Polymer battery	1pc x 3.7V
Operation Voltage	1.8-3.9V	DC
Transmission Circuit	4.5mA (Max)	Tested at 0dBm transmission power
Transmission Range	100 meters	Maximum
Antenna	50ohm	On board / PCB Antenna
Accessories	Double adhesive	1pc, high-strength, 3M brand
Size	90 x 60 x 4 mm	Null

  Features&Advantage   - Programmed MiniBeacon standard firmware - Powered by Lithium polymer battery - The max. 100 meters advertising distance
- Ultra-low power consumption chipset DA14580 with ARM core - Easy to print the logo on the waterproof case   Company Information   Shenzhen Minew Technologies Co., Ltd. (Minew for short) has been focusing on developing and manufacturing iBeacon, bluetooth key finder and other RF technology-based creative products and technical services. As a professional factory, Minew has got the ISO9001:2008 certification.
