unique learning code ask transmitter module with PCB antenna

Specifications 1.learning code

2.ask transmitter

3.PCB antenna

  Features:     1. low working voltage from 2.2V to 3.6V     2. save space, rf circuit and encoder integrated int one chip ITC01T     3. learning code, the code is unique     4. OOK transmitter module     5. PCB antenna, easy to assembly     6. comply with CE (R&TTE) and FCC (Part 15.) regulations     7. RoHS compliant   Provideed max. 6 data input channels more than PT2262's.    OEM and ODM orders are welcomed!

Operation voltage	2.2 - 3.6 Vdc
Standby current	less 2uA
Operation frequency	315MHz, 433.92MHz
Frequency offset	+/- 50KHz
Modulation	ASK (Crystal Oscillator )
Transmission current	less 9mA
Transmission power	10dBm
Channel	6 channels (D0-D5)
Encoder(Optional)	Learning Code, Unique ID
2rd Harmonic	less -36dBm
Antenna	PCB Antenna or External
Size	27mm*21mm*6mm
Certification	CE(R&TTE), RoHS

                                                                Minew company is not only a professional RF / Wireless products design-house, but also a verified manufacturer by Alibaba. Due to our outstanding design capabilities and extensive manufacturing experience, we can rapidly develop and produce RF & Wirelss products as global client's requirements.
>>>>>>>>>>>>>>>>>>  We have been producing wirless remote control, RF transmitter and receiver modules, wireless receiver control switch, wireless detectors(PIR Motion sensor, door soor, gas detector, smoking deteckor, water leaking detector, etc.) and home / business burglar alarm system. Our standard products are exported to Europe, America, Asia , Australia and Africa.   Our service: Turnkey product design & One-stop manufacturing We will be pleased to begin working with you!
