EM9916AE - 125KHZ RFID RS232 & WG26 Reader

Get Latest Price

Delivery Time:: 2 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China (Mainland)

Product Description

EM9918

AE - 125KHZ RFID RS232 READER This reader is supplied in a PCB board containing RF circuits, an 8-bit microcontroller and data output connections. Features

. 125KHz carrier frequency
. Reading of amplitude-modulated transponders
. Efficient tag management
. Easy to build up a control system
. An RFID reader system
. Include A 10-cm diameter square antenna coil
. An external DC 9V voltage that provides
. 0.2A current power supply is needed.
. The card with EM format is needed

. 125KHz carrier frequency

. Reading of amplitude-modulated transponders

. Efficient tag management

. Easy to build up a control system

. An RFID reader system

. Include A 10-cm diameter square antenna coil

. An external DC 9V voltage that provides

. 0.2A current power supply is needed.

. The card with EM format is needed

Specifications

1) Power Supply : DC12V, 200mA
2) Output : RS232 & WG26
3) Reading Range : 8-10cm for ISO card
4) Reading Speed: Less than 70mS
5) Frequency: 125KHz carrier frequency
6) Operating Temperature: -20 to +50°C
7) Storage Temperature: -30 to +60°C
8) Humidity: 5-95%RH

1) Power Supply : DC12V, 200mA

2) Output : RS232 & WG26

3) Reading Range : 8-10cm for ISO card

4) Reading Speed: Less than 70mS

5) Frequency: 125KHz carrier frequency

6) Operating Temperature: -20 to +50°C

7) Storage Temperature: -30 to +60°C

8) Humidity: 5-95%RH

The Data Connection of Reader:

Number	Color	Name	Description
1	BLACK	GND	GND
2	RED	DC +12V	DC +12V POWER
3	GREY	NC	NO USE
4	YELLOW	D0	WEIGAND 26 DATA0
5	GREEN	D1	WEIGAND 26 DATA1
6	WHITE	LED	LED Control line, the color of the light from red to green as LED pulled down.
7	BLUE	BEEP	Buzzer Control line, the buzzer beep as BEEP pulled down.
8	BROWN	RS232	Rs232 data line
