Commercial 13 Seer Air Handler Air Conditioner

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

Commercial 13 Seer Air Handler Air Conditioner Specifcation

Matched outdoor(indoor) unit sale models			YOV3-36HR
Power supply		V-Ph-Hz	208/230/1Ph/60Hz
Cooling	Capacity	Btu/h	35000
	Input	W	330
	Rated current	A	1.65
Heating	Capacity	Btu/h	36000
	Input	W	330
	Rated current	A	1.65
Electric Heater(Optional)		kW	10
Indoor fan motor	Model		YDK200-8H
	Type		AC Motor
	Brand		YongAn
	Drive	type
	Output	W	200
	Input	W	295
	Capacitor	μF	5
	Speed	r/min	740
	Rated current	amps	1.32
Fan dimensions	diameterxlength	inch	12-1/4x10-1/4
Indoor coil	a.Number of rows		3
	b.Tube pitch(a)x row pitch(b)	inch	1×7/8
	c.Fins per inch		13
	d.Fin type (code)		Hydrophilic aluminium
	e.Tube outside dia.and type	inch	3/8''
	e.Tube outside dia.and type	inch	innergroove tube
	f.Coil length x height x width	inch	16-5/8x22x3
	g.Number of circuits		6
	h.Face area	sq-ft	5.08
Indoor air flow		m³/h	2180
Indoor air flow		CFM	1286
Indoor external static pressure		inchH₂O	0.16
Indoor noise level(sound pressure)		dB(A)	51.6
Indoor unit	Dimension (WHD)	mm	1219x540x597
	Dimension (WHD)	inch	48x21-1/4x23-1/2
	Packing (WHD)	mm	1290x679x659
	Packing (WHD)	inch	50-3/4x26-3/4x26
	Net/Gross weight	lbs	158.5/171.5
Refrigerant type			R22
Throttle type	Type
Throttle type	Size/ Spec	10^(-3 )inch	JLF(H)-082
Design pressure		10³psi	Pd:0.5 Ps:0.15
Refrigerant piping	Liquid side/ Gas side	inch	3/8/3/4
	Max. Pipe length	ft	82
	Max. Fall	ft	33
Connection wiring	Power wiring	AWG	3x14
Connection wiring	Signal wiring	AWG	9x18
Drainage water pipe dia.		inch	3/4''
Controller
Operation temp		^oF	63~86
Application area		ft²	452~753
Indoor loadage 20’ /40’ /40'HQ		Pieces	39/81/81
Outdoor loadage 20’ /40’ /40'HQ		Pieces	24/56/83
