High Power Wavelength Selectable XL2547P-Type CW DFB Laser Module

High Power Wavelength Selectable XL2547P-Type CW DFB Laser Module

$720.00

10-499 piece
$690.00

500-999 piece
$580.00

≥1000 piece

Min. Order:: 1 piece

Min. Order:: 1 piece

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

High Power Wavelength Selectable XL2547P-Type CW DFB Laser Module

Featuring wavelength selection to the DWDM ITU-T grid, the XL2547P Laser Modules are ideally suited for use with externallithium niobate modulators, and in high-power (20 mW) applications.

The XL2547P-Type DFB laser module is designed foruse with an external lithium niobate modulator andalso in applications where high power (20 mW) isrequired.The laser comes packaged in an industry-standard 14-pin butterfly module with a polarization-maintaining fiber pigtail.Temperature-stabilized with a thermoelectric cooler(TEC) and thermistor, the package is available in Cand L band ITU-T grid wavelengths on a 100 GHzspacing plan.D2547P does not contain a wavelength locker, whichis not needed for high-reliability operation in100GHz-spaced applications.

XL2547P-Type CW DFB Laser Module High Power Wavelength Selectable LED Product

Product Description

High-performance, multiquantum-well (MQW),distributed-feedback (DFB) lasern XL2547P-Type is offered on 100 GHz ITU gridwavelengths ranging from 1528.77 nm—1610.06 nmn Polarization-maintaining fiber pigtailn For use with lithium niobate modulatorsn High optical power (20 mW, CW)n Hermetic, 14-pin package .
