0402 yellow color chip SMD LED with 587-593nm

Specifications 0402 yellow color chip SMD LED with 587-593nm

white,water clear len ,

CE&ROHS certification

 0402  yellow color chip SMD LED with 587-593nm         Applications 1.Backlighting in dashboard and switch 2.Telecommunication: indicator and backlighting in telephone and fax 3.Flat backlight for LCD ,switch and symbol 4.Floppy disk drive 5.Medical equipment 6.Indication light on hand held products       Package Schematics           Initial Electrical/Optical Characteristics                                (Ta=25℃)

Item	Symbol	condition	Min	Type	Max	Unit
DC forward Voltage	VF	I=20mA	1.8	2.0	2.3	V
DC reverse Current	IR	V=5V	----	----	10	μA
Dome Wavelength	WD	I=20mA		590		Nm
Spectrum Radiation Bandwidth	Δλ	I=20mA	----	20	----	nm
Luminous Intensity	Iv	I=20mA	80	180		mcd
50%Power Angle	2θ1/2	I=20mA	----	120	----	deg
