10G LRM 220m XENPAK Optical Transceiver module
- Delivery Time:
- 1 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Guangdong, China (Mainland) |
|---|
Product Description
Product Description
Specifications -10G XENPAK
-1310nm DFB laser
-SC-Duplex, Reach to 220m MMF
-Compliant to XENPAK MSA
-10GBASE-LR Application
10G 1310nm 220m LRM XENPAK Optical Transceiver module Product Description Overview: The 10GBASE XENPAK modules offers a wide variety of 10 Gigabit Ethernet connectivity options for data center, enterprise wiring closet, and service provider transport applications. Semi Matrix's 10Gb/s XENPAK transceiver module is a hot pluggable in the Z-direction module that is usable in typical router line card applications, Storage, IP network and LAN and compliant to XENPAK MSA. This module is a fully integrated 10.3Gbit/s optical transceiver module that consists of a 10.3Gbit/s optical transmitter and receiver, XAUI interface, Mux and De-mux with clock and data recovery(CDR).
This transceiver line uses an 1310nm DFB laser achieve 220m over MMF as 10GBASE-LR of the IEEE 802.3ae. Main Features: 1. XAUI Electrical Interface: 4 Lanes @ 3.125Gbit/s
2. SC Receptacle 1310nm DFB Laser
3. Hot Pluggable 70-PIN Connector with XAUI Electrical Interface
4. Power Supply :+3.3V, APS(+1.2V)
5. MDIO, DOM Support
6. reach to 220m
7. Compliant to XENPAK MSA
8. Support of IEEE 802.3ae 10GBASE-LR at 10.3125Gbps
9. Case operating temperature: 0 to 70 °C
10. RoHS6 compliant and lead free Applications: 1. 10GE Ethernet switches and routers
2. 10GE Core-routers
3. 10GE Storage
4. Other 10Gbps Ethernet Transmission System Customized Service Semi Matrix provides OEM, ODM and other Customized services to the customers who required. We supply the suitable Optical Solution according to your requirements, and design the label and packaging as you need. Welcome any inquiry of customized products and service. Compatibility Our Optical Transceiver module can work compatible with all brands, Please inform the brand name of your system when you make the order. Thanks.
Detailed Images
Packaging & Shipping
Payment & Warranty We offer 3 year warranty to our products.
Ordering Information
-1310nm DFB laser
-SC-Duplex, Reach to 220m MMF
-Compliant to XENPAK MSA
-10GBASE-LR Application
10G 1310nm 220m LRM XENPAK Optical Transceiver module Product Description Overview: The 10GBASE XENPAK modules offers a wide variety of 10 Gigabit Ethernet connectivity options for data center, enterprise wiring closet, and service provider transport applications. Semi Matrix's 10Gb/s XENPAK transceiver module is a hot pluggable in the Z-direction module that is usable in typical router line card applications, Storage, IP network and LAN and compliant to XENPAK MSA. This module is a fully integrated 10.3Gbit/s optical transceiver module that consists of a 10.3Gbit/s optical transmitter and receiver, XAUI interface, Mux and De-mux with clock and data recovery(CDR).
This transceiver line uses an 1310nm DFB laser achieve 220m over MMF as 10GBASE-LR of the IEEE 802.3ae. Main Features: 1. XAUI Electrical Interface: 4 Lanes @ 3.125Gbit/s
2. SC Receptacle 1310nm DFB Laser
3. Hot Pluggable 70-PIN Connector with XAUI Electrical Interface
4. Power Supply :+3.3V, APS(+1.2V)
5. MDIO, DOM Support
6. reach to 220m
7. Compliant to XENPAK MSA
8. Support of IEEE 802.3ae 10GBASE-LR at 10.3125Gbps
9. Case operating temperature: 0 to 70 °C
10. RoHS6 compliant and lead free Applications: 1. 10GE Ethernet switches and routers
2. 10GE Core-routers
3. 10GE Storage
4. Other 10Gbps Ethernet Transmission System Customized Service Semi Matrix provides OEM, ODM and other Customized services to the customers who required. We supply the suitable Optical Solution according to your requirements, and design the label and packaging as you need. Welcome any inquiry of customized products and service. Compatibility Our Optical Transceiver module can work compatible with all brands, Please inform the brand name of your system when you make the order. Thanks.
Detailed Images Packaging & Shipping Payment & Warranty We offer 3 year warranty to our products. Ordering Information | Part number | Package Style | Data Rate | Distance | LD | PD |
| 10G-XENPAK-SR | XENPAK | 10Gb/s | 300m | 850nm VSCEL | PIN |
| 10G-XENPAK-LRM | XENPAK | 10Gb/s | 220M | 1310nm DFB | PIN |
| 10G-XENPAK-LR-10 | XENPAK | 10Gb/s | 10km | 1310nm DFB | PIN |
| 10G-XENPAK-LR-20 | XENPAK | 10Gb/s | 20km | 1310nm DFB | PIN |
| 10G-XENPAK-ER-40 | XENPAK | 10Gb/s | 40km | 1550nm Cooled EA-DFB | PIN |
| 10G-XENPAK-ZR-80 | XENPAK | 10Gb/s | 80km | 1550nm Cooled EA-DFB | APD |
