Catalyst 3750 Series Campus LAN Acess Switch WS-C3750G-24TS-E1U
- Delivery Time:
- 1 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Guangdong, China (Mainland) |
|---|
Product Description
Product Description
Specifications -WS-C3750G-24TS-E1U
-24 Ethernet 10/100/1000 ports
-4 SFP-based Gigabit Ethernet ports
-IP Services
-1 RU stackable
Catalyst 3750 Series Campus LAN Acess Switch WS-C3750G-24TS-E1U Product Description Product Overview The Cisco Catalyst 3750 Series Switches are innovative switches that improve LAN operating efficiency by combining industry-leading ease of use and high resiliency for stackable switches. This product series features Cisco StackWise technology, a 32-Gbps stack interconnect that allows customers to build a nified, highly resilient switching system, one switch at a time.
Specifications WS-C3750G-24TS-E1U
Payment & Warranty We offer 3 years warranty to our products.
Ordering Information
Packaging & Shipping Cisco ORIGINAL NEW IN BOX WITH EXTRA PROTECTION.
-24 Ethernet 10/100/1000 ports
-4 SFP-based Gigabit Ethernet ports
-IP Services
-1 RU stackable
Catalyst 3750 Series Campus LAN Acess Switch WS-C3750G-24TS-E1U Product Description Product Overview The Cisco Catalyst 3750 Series Switches are innovative switches that improve LAN operating efficiency by combining industry-leading ease of use and high resiliency for stackable switches. This product series features Cisco StackWise technology, a 32-Gbps stack interconnect that allows customers to build a nified, highly resilient switching system, one switch at a time.
Specifications WS-C3750G-24TS-E1U | GENERAL | |
| Device Type | Switch - 24 ports - L3 - Managed - stackable |
| Enclosure Type | Rack-mountable - 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 + 4 x SFP |
| Performance | Switching capacity : 32 Gbps |
| Forwarding performance : 38.7 Mpps | |
| MAC Address Table Size | 12K entries |
| Jumbo Frame Support | Yes |
| Max Units In A Stack | 9 |
| Routing Protocol | IGRP, BGP-4, IS-IS, RIP-1, RIP-2, HSRP, PIM-SM, static IP routing, PIM-DM, EIGRP for IPv6, OSPF for IPv6, policy-based routing (PBR), RIPng |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, SSH, CLI |
| Authentication Method | Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
| Features | Flow control, full duplex capability, Layer 3 switching, auto-sensing per device, IP-routing, DHCP support, auto-negotiation, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, stackable, IPv6 support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, Jumbo Frames support, Cisco StackWise Technology, Cisco EnergyWise technology, Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s |
| RAM | 128 MB |
| Flash Memory | 32 MB Flash |
| Status Indicators | Link activity, port transmission speed, port duplex mode, bandwidth utilization %, system, RPS (Redundant Power Supply) |
| EXPANSION / CONNECTIVITY | |
| Interfaces | 24 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
| 1 x console - RJ-45 - management | |
| 1 x network stack device x 2 | |
| 4 x SFP (mini-GBIC) | |
| POWER | |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V ( 50/60 Hz ) |
| Power Consumption Operational | 100 Watt |
| Features | Redundant Power System (RPS) connector |
| MISCELLANEOUS | |
| MTBF | 221,150 hours |
| Compliant Standards | FCC Class A certified, TUV GS, BSMI CNS 13438 Class A, CISPR 24, cUL, EN 60950, EN55022, NOM, VCCI Class A ITE, IEC 60950, EN55024, UL 60950 Third Edition, CISPR 22, CSA 22.2 No. 60950, CB, FCC Part 15, MIC, AS/NZS 3548 |
| SOFTWARE / SYSTEM REQUIREMENTS | |
| Software Included | Cisco IOS IP Services |
| DIMENSIONS & WEIGHT | |
| Width | 44.5 cm |
| Depth | 37.8 cm |
| Height | 4.4 cm |
| Weight | 5.5 kg |
| MANUFACTURER WARRANTY | |
| Service & Support | Limited lifetime warranty |
| Service & Support Details | Limited warranty - lifetime |
| ENVIRONMENTAL PARAMETERS | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 10 - 85% (non-condensing) |
| Min Storage Temperature | -25 °C |
| Max Storage Temperature | 70 °C |
Ordering Information Part Number | Description |
| WS-C3750G-24TS-E1U | 24 Ethernet 10/100/1000 ports |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Services software feature set (IPS) | |
| Provides full IPv6 dynamic routing | |
| WS-C3750G-24TS-S1U | 24 Ethernet 10/100/1000 ports |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750G-24TS-E | 24 Ethernet 10/100/1000 ports |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1.5 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Services software feature set (IPS) | |
| Provides full IPv6 dynamic routing | |
| WS-C3750G-24TS-S | 24 Ethernet 10/100/1000 ports |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1.5 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750G-24WS-S25 | 24 Ethernet 10/100/1000 ports with IEEE 802.3af and Cisco prestandard PoE |
| 2 SFP-based Gigabit Ethernet ports | |
| Integrated Wireless LAN Controller | |
| Supports up to 25 Lightweight Access Points | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 2 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750G-24WS-S50 | 24 Ethernet 10/100/1000 ports with IEEE 802.3af and Cisco prestandard PoE |
| 2 SFP-based Gigabit Ethernet ports | |
| Integrated Wireless LAN Controller | |
| Supports up to 50 Lightweight Access Points | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 2 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750G-24T-E | 24 Ethernet 10/100/1000 ports |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Services software feature set (IPS) | |
| Provides full IPv6 dynamic routing | |
| WS-C3750G-24T-S | 24 Ethernet 10/100/1000 ports |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750G-12S-E | 12 SFP-based Gigabit Ethernet ports |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Services software feature set (IPS) | |
| Provides full IPv6 dynamic routing | |
| WS-C3750G-12S-S | 12 SFP-based Gigabit Ethernet ports |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750G-12S-SD | 12 SFP-based Gigabit Ethernet ports |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable multilayer switch | |
| DC Power Supply | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750G-16TD-E | Sixteen 10/100/1000 Gigabit Ethernet ports |
| One IEEE 802.3ae 10 Gigabit Ethernet XENPAK port | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Services software feature set (IPS) | |
| Provides full IPv6 dynamic routing | |
| IEEE 802.3ae 10 Gigabit Ethernet port is 1.25:1 oversubscribed | |
| WS-C3750G-16TD-S | Sixteen 10/100/1000 Gigabit Ethernet ports |
| One IEEE 802.3ae 10 Gigabit Ethernet XENPAK port | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable multilayer switch | |
| Delivers enterprise-class intelligent services to the network edge | |
| IP Base software feature set (IPB) | |
| IEEE 802.3ae 10 Gigabit Ethernet port is 1.25:1 oversubscribed | |
| WS-C3750G-24PS-E | 24 Ethernet 10/100/1000 ports with IEEE 802.3af and Cisco prestandard PoE |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Services software feature set (IPS) | |
| Provides full IPv6 dynamic routing | |
| WS-C3750G-24PS-S | 24 Ethernet 10/100/1000 ports with IEEE 802.3af and Cisco prestandard PoE |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750G-48TS-E | 48 Ethernet 10/100/1000 ports |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Services software feature set (IPS) | |
| Provides full IPv6 dynamic routing | |
| WS-C3750G-48TS-S | 48 Ethernet 10/100/1000 ports |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750G-48PS-E | 48 Ethernet 10/100/1000 with IEEE 802.3af and Cisco prestandard PoE ports |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Services software feature set (IPS) | |
| Provides full IPv6 dynamic routing | |
| WS-C3750G-48PS-S | 48 Ethernet 10/100/1000 with IEEE 802.3af and Cisco prestandard PoE ports |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750-48PS-E | 48 Ethernet 10/100 ports with IEEE 802.3af and Cisco prestandard PoE |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Services software feature set (IPS) | |
| Provides full IPv6 dynamic routing | |
| WS-C3750-48PS-S | 48 Ethernet 10/100 ports with IEEE 802.3af and Cisco prestandard PoE |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750-48TS-E | 48 Ethernet 10/100 ports |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Services software feature set (IPS) | |
| Provides full IPv6 dynamic routing | |
| WS-C3750-48TS-S | 48 Ethernet 10/100 ports |
| 4 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750-24PS-E | 24 Ethernet 10/100 ports with IEEE 802.3af and Cisco prestandard PoE |
| 2 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Services software feature set (IPS) | |
| Provides full IPv6 dynamic routing | |
| WS-C3750-24PS-S | 24 Ethernet 10/100 ports with IEEE 802.3af and Cisco prestandard PoE |
| 2 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750-24TS-E | 24 Ethernet 10/100 ports |
| 2 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Services software feature set (IPS) | |
| Provides full IPv6 dynamic routing | |
| WS-C3750-24TS-S | 24 Ethernet 10/100 ports |
| 2 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) | |
| WS-C3750-24FS-S | 24 100BASE-FX ports |
| 2 SFP-based Gigabit Ethernet ports | |
| 32-Gbps, high-speed stacking bus | |
| Innovative stacking technology | |
| 1 RU stackable, multilayer switch | |
| Enterprise-class intelligent services delivered to the network edge | |
| IP Base software feature set (IPB) |
Related Keywords
Related Keywords
You May Also Like
You May Also Like
-
HP X120 1G SFP LC BX 10-U Transceiver JD098B
HP X125 1G SFP RJ45 T Transceiver JD089B
HP X120 1G SFP LC LH100 Transceiver JD103A
Related Products-
Catalyst 3750 Series Campus LAN Acess Switch WS-C3750G-24TS-E1U
-
Catalyst 3850 Series Campus LAN Access SFP Switch WS-C3850-24S-S
-
Catalyst 3850 Series Campus LAN Access SFP Switch WS-C3850-24S-E
-
Catalyst 3850 Series Campus LAN Access SFP Switch WS-C3850-12S-S
-
Catalyst 3850 Series Campus LAN SFP Switch WS-C3850-12S-E
