Sungold Foldable 80W Solar Panel

$90.00 - $106.00/set

Min. Order:: 100 set

Min. Order:: 100 set

Port:: Shenzhen port

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Supply Ability:	6500000 Watt/Watts per Month
Payment Type:	L/C,Western Union,T/T
Port:	Shenzhen port

Product Description

Product Parameters

Specifications -LVP series
Component Model	LVP-2*40w	LVP-2*45w	LVP-2*50w	LVP-2*60w	LVP-2*100w
Maximum power	80W	90W	100W	120W	200W
Operating voltage(Vmp)	19.8	19.8	19.8	19.8	19.8
Curent(lmp)	4.04	4.55	5.05	6.03	10.71
Open cicuit voltage(Voc)	23.4	23.4	23.4	23.4	23.4
Short-circuit current(Isc)	4.28	4.82	5.35	6.42	10.1
Cells Efficiency(%)	18.43%	18.43%	18.43%	18.43%	18.43%
Operating Temperature(℃):	（-10℃~60℃）
Power temperature coefficient	—0.43%/℃
Voltage temperature coefficient	—0.34%/℃
Current temperature coefficient	—0.55%/℃
Output power tolerance	±3%
Cell effciency	20.60%
Life	10 years
Warranty	1 years
Maximnum system voltagea	60V DC
Junction box	IP65 or IP67 rated
Folding size	51051550mm	56051550mm	61551550mm	71551550mm	80068550mm
Weight	4.5kg	5.0kg	5.5kg	6.3kg	9.5kg
Measured at STC Condition: irradiance: 1000W /m㎡-AM1.5 Spectrum-Temperature: 25℃
Electrical parameters may vary by ±3%

Product Details

Client Feedback

About Us

Shenzhen Sungold Solar Co., LItd

Sungold Advantages:
-The professional producing experience of solar panel for 13 years
Accumulating the experience for more than a decade,Sungold has become a company with mature technology and management system

-Outstanding quality
With the certificates of ISO, RoHS, CE, etc. We professionally provide high quality products with automated production line.

-Professional techniques and service
Every Sungold product is crafted according to the needs of customer, also, the service we do is all for customer.

Exhibition & Certificate

Logistics Transportation

1)Q:The price is too expensive,why? We choose the best material to make. All SunPower A grade cells are imported from the USA, and we insist on the development of quality. 2)Q:What is the payment term? 100% T/T in advance 30% T/T in advance balance before shipment when your order over 10000usd 3)Q:Why is the delivery time too long? It depends on your quality of order and product type: If you only need a sample, we can send you soon. 4)Q:What is mono and poly panels? The panel adopts mono-crystalline and poly-crystalline cells. 5)Q:What is the different between mono and poly? The cells conversion efficiency is different. The mono cell is higher than poly one. Mono is 20.6%, and poly is 18.3%, so mono panel is more expensive than poly panel. 6)Q: What is the warranty of the panel? Mono panel and poly panel has 10 years warranty. Flexible panel has 1 year warranty and 5 year service time. Customers told a panel was bought in 2012 is still working. 7)Q: What is the package of the flexible panel? 1 pcs is put in a bubble bag and one carton and 10pcs are put in bigger carton, then wooden pallet. 8)Q: How many workers in Sungold? Almost 300. 9)Q: Do you have any certificates on the panels? CE, ROHS and ISO. 10)Q: Can you do OEM for my panels? Yes, we support OEM and ODM.
