LSO12-665D Hydraulic Dock Leveler
- Delivery Time:
- 20 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Guangdong, China (Mainland) |
|---|
Product Description
Product Description
Specifications LSO12-665D Hydraulic Dock Leveler
working by oil hydraulic and motor power.
Strong main structure,strong capacity.
hydraulic dock levelers : 1.Dock leveler series main products covering:hydraulic,airbag and mechanical style. 2.Special streamline open mobile joint design 3.Special steel I-frame work 4.Deck board thickness:8mm 5.lip board thickness:16mm lip length:400mm 6.Motor:0.75kw 220V/380V 7.Hydraulic from Italy 8.Pit shoud be prepard before installed according to our design drawing 9.Standard length:8ft,10ft;Width;6ft ,7ft 10.Capacity:6mt 10mt 15mt 22mt Sheet for our standard model:
working by oil hydraulic and motor power.
Strong main structure,strong capacity.
hydraulic dock levelers : 1.Dock leveler series main products covering:hydraulic,airbag and mechanical style. 2.Special streamline open mobile joint design 3.Special steel I-frame work 4.Deck board thickness:8mm 5.lip board thickness:16mm lip length:400mm 6.Motor:0.75kw 220V/380V 7.Hydraulic from Italy 8.Pit shoud be prepard before installed according to our design drawing 9.Standard length:8ft,10ft;Width;6ft ,7ft 10.Capacity:6mt 10mt 15mt 22mt Sheet for our standard model:
Style | Size(W*L) | Adjust | pit width | Pit length | Pit depth |
| Hydraulic 6’*8’ | 1830mm*2440mm
| +350 -300 | 1870 mm | 2210 mm | 500(front) 490(back) |
| Mechanic 6’*8’ | 1830mm*2440mm
| +350 -300 | 1870 mm | 2210 mm | 500(front) 490(back) |
| Air bag 6’*8’ | 1830mm*2440mm
| +350 -300 | 1870 mm | 2210 mm | 500(front) 490(back) |
| Mobile 6’*8’ | 1830mm*2440mm
| +300 -0 | no | no | no
|
| Manual side 6’*8’ | 1830mm*380mm 2130mm*380mm | +150 -150 | no | no | no |
Electric side | 1830mm*300mm | +200/-300 | no | no | no |
Edge of dock leveler | 1800*350*1200 | +200/-300 |
|
|
|
