Bilateral aisle-stacking Parking System

Specifications The tool of access the vehicle is the stacker which can back & forth and up & down operation.

1.Working Principle
The tool of access the vehicle is the stacker which can back & forth and up & down operation. It can accurate reach to every parking space by combining with control of the PLC system and computer. Please drive to the parking platform when parking. Then the stacking machine will begin to run into the vacancy in the roadway after the people left. And the vehicles will be sent into the right positions through the precise counterpoint of the computer. When pick up, it is on the contrary.
2. Features
Intelligent control with high degree of automation and efficient.
Highly space utilization, stacking decks from 2 layers to about 10 layers.
Use of steel manufacturing, the entire composite structure, convenient and efficient, simple maintenance.
It can also adopt concrete structures, fully closed construction, more security and efficiency, permanent use.
Multiple security measures to allow you to use without any worry. Such as anti-fall device, photoelectric sensors and anti-overrun etc. 3.Technical parameter

1	Specification	5500mm(L)*1900mm(w)*1700mm(H)
2	Designed layer	2~12 layers
3	Designed capacity	2000KG
4	Back & forth motor power	3.0KW
5	Up & down motor power	7.5KW
6	Left & right access motor power	0.75KW
7	Back & forth operation speed	70m/min
8	Lifting operation speed	30m/min
9	Left & right operation speed	50 m/min
10	Voltage	380V/50HZ
11	Safety devise	Fall protection, anti-collision, vibration reduction, emergency stop, etc.
12	Control mode	PLC & computer
