Olyair HR Mini VRF: Simultaneous Hot Water, Cooling, and Heating Solutions

Olyair VRF Central air conditioning hot water system with HR technology

VRF system is well flexible designed for applicable for a variety of occasions. Offering a higher capacity up to 64HP,in 2 HP  as  an  increments,  meeting  to  the  needs  of  requirements.  It  also  incorporates numerous outstanding features, a large capacity range of outdoor units and indoor units,  longer  level  difference  and  actual  piping  and  high  external  static  pressure.
The  VRF  product  provides  a  flexible  design  and  easy  installation  in big-sized and high-rise building for wide application

Pioneering  acomplished VRF system machine with cooling heat and hot water function, rich choice of indoor unit plus can provide uninterrupted domestic hot water all year round, achieve energy saving and also save the installation cost, one step to have cooling heat and hot water machine.

Mainly Features:

1.   HIGH EFFICIENCY

High efficiency VRF with high efficient DC compressor and DC motor, realized an EER up to 4.29 (8 HP) and achieved the world’s Top Class energy efficiency. Enhanced Rated Heat Capacity. Wide operation Range. No matter in extremely cold winter when outdoor temperature down to as low as -4°F(-20°C)or in hot summer when temperature is up to 118°F(48°C), the V4+ system will keep stable operation. Intelligent defrost improve the heat capacity.

2. ENHANCED COMFORT

Intelligent soft start technology

DC inverter compressor soft start function reduces strike to the electric network. This kind of high-performance and low sound scroll compressor operates at a faster rate when starting, reducing start-up time. It helps the unit to bring the room temperature up to the set level quickly.8, 10HP(7.2,8Ton)

Utilizing the scroll compressor benefits,VRF system can  reach  full  load  quickly  and  shorten  warm-up  or cool-down time for an immediately.Quick warm-up & cool-down design

Night time silent operation mode

OlyAir's Night Silent Mode feature which is easily set on the PCB board allows the unit to be set to varies time options during Non Peak and Peak operation time optimizing the units noise output. Extra silent operation mode can reduce sound level further, minimum 46.8dB (A). Nighttime silent operation will be activated X hours after the peak temperature during daytime, and it will go back to normal operation after Y hours.

3. High efficiency oil balance and oil return technology

Oil balance pipes among modules and individual oil balance by vector control ensure even oil distribution among the
modules which keeps compressor running nomally. High effciency centrifugal oil separator(up to 99%)
makes oil separate from discharge and go back to compressor. Auto oil return program by monitoring the running time and state of system ensures reliable oil return.

4. HIGHER RELIABILITY
In one combination, any of the outdoor unit can run as the master outdoor unit, to realize the equal lifespan among the outdoor units in the combination. Alternative Cycle Duty  operation of outdoor units.  Any single unit can be set as the master unit in a multiple system when the previous master unit failed and other units left will keep on operating. This can be set on PCB by DIP switches at site.Outdoor module Back up operation.

5.FLEXIBILITY DESIGN FOR BIG SIZED BUILDING
The outdoor units  capacity range from 8HP up to 64HP (7.2~51.5 ton) in 2HP increment.Maximum 64 indoor units with capacity  up to 130% of total outdoor units can be connected as one refrigeration system.Large capacity for big sized building.

If you have any project or business opportunity for VRF system need to accomplish hot water also for multi choice of the indoor unit for cool and heat, welcome to discuss with us. We can draw the technical diagram for u and full solution based on your VRF system choice. Thanks for attention !
