water purification plant

Specifications water purification plant

1.high grade reverse osmosis filtration tech

2.anto-control & protect system

3.long service life

  drinking water treatment plant Pictures:     Key Specifications:

Rating Output	15000L/H    25°C
Power Consumption	19 KW
Power Input	AC380V  35A  50Hz
RO Membrane	ESPA-8040 15 items (Single grade)
sand filter	Φ1400 x1000 1 item   3000KG
carbon filter	Φ1400 x1000   1 item    1000KG
water softener	optional
PP filter	Φ400x1000mm 1 item
booster pump	CR20-3/4kw 1 item
multi-stages pump	CR20-14/15KW  1item

  Out size of main machine(mm): 6000x925x1700 Out size of beforehand filter(mm): 4100x1870x3000 Main function: 1. Manual or Auto Washing mode for RO Membrane.
2. On line manually wash RO Membrane with chemical.
3. Automatic stop when purified water is full.
4. Auto-stop when the water source is not enough.
5. showing the Conductvity value.
6. stainless steel structure .
7. No voltage, under voltage, over current, short circuit, open circuit and current leakage protection.
8. Using the FILMTEC brand ro membrane,the desalting Rate: more than 98%.         Application: drinking and water bottle factory
