Quad band 8 channels WCDMA fixed wireless terminal/ 3g wcdma terminal

Name: 3G WCDMA Fixed Wireless Gateway Model: VIN-888 (8 SIM Cards)    Features:       1) 8RJ11 ports with 8 SIMCards       2) Multimode operation HSUPA/HSDPA/UMTS/EDGE/GPRS/GSM
      3) Providing 900MHz/1800/850/1900/2100MHz band frequency       4) Triple-band HSPA/UMTS 850/1900/2100 MHz
      5) Quad-band EDGE/GPRS/GSM 850/900/1800/1900 MHz       6) Adopt Industral Module(3G Engine) to ensure good performance
      7) IMEI changed(optional)
      8) Simple to install/easy to maintain
      9) Allow PIN code entering and reciprocal phone-card lock
      10) Provide optimized circuit directly connecting the exchange device for extensions
      11)Polarity reversal signal for billing metering
      12) 3.5dBi gain antenna
      13) Compatible to PABX, VoIP gateway, IP PBX, Call back system, cord phone, Voice system, and etc.
      14) Suitable for call termination of ISP
      15) Dialing tone
      16) DTMF Dialing
      17) Caller ID With DTMF and FSK
      18) Hide calling out number.
      19) Working state indicator
      20) Signal Strength indicator   Technical data:
    1) Air interface standard: GSM and 3G WCDMA 900/1800/850/1900/2100 MHz Band freequncy
    2) Sensitivity: -104dB
    3) Peak power consumption: 16W
    4) Phone interface: Supply RJ-11 Phone Interface Hanging voltage: 48V.
    5) Dialing tone Frequency: 450Hz
    6) Operating environment requirements:
    7) Temperature: 0C - +40C
    9) Relative humidity: 45% - 90%
    10) Connectors: SMA antenna connector
    11) Atmospheric pressure: 86~106Pka
    12) Power consumption: Static≤ 200 mA, emission≤ 4000 mA
    13) Antenna: Gain: 3.5dB (all directional) 12 dB(Certain/selection)
Power supply:
    AC220V more or less 10% 47-54Hz AC110V/60Hz( optional)
    DC12V ( optional)

              If you have any other questions,contact us now!        We look forward to cooperat with you!                skype: Janeheee               trademanager: vintelecom
