2.4G WiFi Internet GSM GPRS Home House Security Alarm System smoke detector APP ip camera

  2.4G WiFi Internet GSM GPRS Home House Security Alarm System smoke detector APP ip camera   Product Description   Innovative GSM & WIFI dual network operating platform. On WIFI network, the alarm system will work without any fee. If no WIFI, it will work on GSM automatically. With state-of-the-art WIFI network technology, the system more stable, safer. Two-way communication, keep checking the commnunication between the panel and accessories, make sure the system safer. The system's APP integrated the IP camera to realize the video record, send pictures to user’s Email when  alarming. 1 slave wired relay output, support alarm output, APP control output. 20 slaves wireless smart home control to switch light, and other home appliances. Set up to 4 scenes, 8 slaves relay per scene. Wireless encode function, support 10 keyfobs/keypads, 24 wireless zones, 4 wired zones & 4 RFID zone. Zone name/content could be edited by yourself, and set alarm delay or not. APP push message including alarm zone and sensor’s name when alarming. APP check the system in real-time: AC power OK or not; system Arm or Disarm; sensor low voltage or not; sensor connect to panel or not; the zone has accessories or not. Check the system's status clearly in time.   Answer alarming calls & Remotely make call to the alarm panel ( with voice prompt ) to start monitoring, voice  intercom, talk back, arm/disarm. Answer calls like a cell phone. Support wired and wireless siren. Support CID protocol. Factory reset. Technical parameters

Power supply	input AC=100 ~ 240V, output DC =12V
Static current	<50mA (when not in charging , excluding wired detectors)
Alarm current	<120mA (excluding wired siren)
GSM transmission power	2W
WIFI frequency	2.4G, built-in wireless internet protocol IEEE802.11b/g and TCP/IP protocol stack
WIFI receiving sensitivity	-86dbm; Emitting power 18dbm
Wireless Frequency	433/868MHZ
GSM frequency	850/900/1800/1900
Backup battery	3.7V/1200MA/H; Standby
12 hours or more; Charge	12 hours full
Wireless receiving distance	> 100 meters (open space)
Wireless transmission distance	> 100 meters (open space)
Work condition	Temp -10 º C ~ 70 º C , RH 5% ~ 95%

  Detailed Images     Certifications     https://youtu.be/y5Ndg2uaa9A
