wireless PIR detector support with 110db

Specifications 1. Wireless Standard PIR Motion Detector

2. 20m transmit distance in the open air

3. 315MHz and 433MHz for choice

  wireless PIR detector support with 110db Features:     1. MCU processing adopted 2. Automatically identify valve control 3.Wireless transmitting digital signal 4. Low power indication 5. Automatic temperature compensation 6. SMT adopted, anti-RFI & anti-EMI 7.Low power consumption, long battery life 8 Pulse count optional     Specifications:

Product type	DP-85R(Pet-proof)
Operating voltage	9V(powered by battery)
Static current	≤25uA
Alarm current	≤15mA
Detecting distance	12m
Detecting angle	110 degree
Code form	2262 or 1527
Radio frequency	315MHZ or 433 MHZ
Radio distance	200m(open area)
Low battery indicator	yellow LED
Alarm indicator	red LED
Sensor	dual element infrared sensor
Operating temperature	-10°C to +50°C
Enviroment humidity	≤95%RH(no congelation)
Anti RF interference	10MHz-1GHz 20v/m
Installation mode	wall mounted or hanged in corner
Installation height	1.7-2.5m(2.2m is proposed)
Outline size	59L*45W*107Hmm
Range of coverage	11 distance
