Wireless Smoke Detector Sensor \ Smoke Fire Alarm

   Wireless Smoke Detector Sensor \ Smoke Fire Alarm Model: JKD-516  PRODUCT INTRODUCTION     The product is a new smoke detector, hereinafter called detector. With a unique structure design and an intelligent MCU to process photoelectronic signals, it is provided with dust-proof, mothproof and anti-light interference etc. functions, ensuring the detector stability from design basis and suitable for all kinds of installation environments and also with the optional wireless interconnection function. It reacts very quick to visible smoke released by smoldering fire and flaming fire, and suitable for fire alarm in house, factories, shopping malls, hotels, restaurants, office buildings, teaching buildings, banks, libraries, warehouses, etc..    PRODUCT FEATURE     Adopts MCU Auto-Processing Technology    Wireless Interconnection Alarm (Optional)    Low-battery warning    Auto-Reset after trigger    Infrared Photoelectronic Sensor   Sound & Flash Alarm & LED indicating Alarm   SMT Manufacture Technology, Reliable Stability   Dust-proof, Mothproof and Anti White light interference TECHNICAL PARAMETER

Model No.	JKD-516
Power Supply	9V battery (6F22 carbon battery, DC TYPE)
Static current	<10uA
Alarm current	<35mA
Sensitive level	2.06%/ft ± 1.3
Alarm indication	Big Area LED flashes in Red
Alarm Sound	85dB/3m
RF	315MHz/433MHz (Wireless TYPE)
Transmitting Distance	200 meters (Open)
Temperature	-10~50 ℃
Relative Humidity	≤95%RH
Dimensions	112*32mm
Execution standard	GB4715-2005, En14604, UL217
Detecting area	80 at 6-12m installation height; 60 at installation height <6m
