high performance shielding microphone cable

Specifications high performance shielding microphone cable

1)with CE certification

 high performance shielding microphone cable          Microphone cable       2CX20/0.12mm OFC
I.D:1.3mm PE+Cotton Yarn +60/0.12 OFC Braiding
O.D:6.0mm Super Flexible PVC       Application       Flexible and reliable for signal transmission at frequences cables. For microphones and musical instruments.           Packing & Shipping           Packing length : 40m/roll ,60m/roll ,91.4m/roll 100m/roll , 200m/roll , 300m/roll ; 305m/roll   Inner packing : plastic cover / wooden drum / paper drum ;   Outer packing : 2/4/ 6 roll / carton box ;   Other packing according to customers’ request !

ITEM NAME	MICROPHONE CABLE
CONDUCTOR	CCS/CCA/PURE COPPER/OFC
SPECIFICATION	AS REQUIRED
LENGTH(M)	AS REQUIRED
PACKING	COIL / PLASTIC SPOOL

      Item No.:A104060.128mesh
Conductor:Pure Copper
Specification:40×0.10×2C
Diameter:0.10,Strands:40,Cores:2
Jacket:Transparent
Length:100m

No. of core	Conductor construction		Braid	Outer Diameter (MM)
	AWG	Inner core No./mm
1	26	10/0.12	48/0.12 64/0.12 96/0.12 or as required	5.8
	24	19/0.12		5.8
	22	26/0.12		5.8
	20	42/0.12		5.8
2	26	10/0.12		6
	24	19/0.12		6
	22	26/0.12		6
	20	42/0.12		6
3	26	10/0.12		6
	24	19/0.12		6
	22	26/0.12		6
	20	42/0.12		6
