High performance TC Braid low noise Microphone Cable

  High performance TC Braid low noise Microphone Cable         Product Description  Description of microphone cable :  1.Conductor: Stranded Bare Copper or Tinned Copper 2.No. of Conductor/mm: 2×36/0.10BC 3.Insulation: PVC 4.Indulation Diameter: 1.8+0.15 5.Shield: Al Foil+ Bare Copper or Tinned Copper braided 6.Jacket: Elastic PVC 7.Shield Standard: 96 bind BC 8.Sheath O.D./mm: 6.0+0.2 9.Sheath Style: Black 10.Work Temperature: -20oC~+70oC   Application of microphone cable  : Used for microphone, ,high-fidelity transmission.   Packing of microphone cable :  rolls/  carton box / plastic spool /wood spool/pallet and any others per the customer's request  90meters/roll, 1 roll/PE film, 8~12rolls/carton boxes   Delivery time of microphone cable  : 20days more or less after confirm t/t payment   Advantage of our factory:  1. More than 10 years of producing many kinds of electric wires and cables 2. Conductor can be used pure copper wrie or CCA cheap conductor. 3. competitive price & good service. 4. OEM are welcome. We can also produce standard or non-standard wires and cables.   General products:

Commodity Name: microphone cable

Item No.:C102060.

Conductor:Copper Clad Steel

Specification:36×0.10mm×2

Brading net :0.1mm*96

Outer Diameter:6mm

Jacket:Transparent PVC

Length:100m



No. of core	Conductor construction		Braid	Outer Diameter (MM)
	AWG	Inner core No./mm
1	26	10/0.12	48/0.12 64/0.12 96/0.12 or as required	5.8
	24	19/0.12		5.8
	22	26/0.12		5.8
	20	42/0.12		5.8
2	26	10/0.12		6
	24	19/0.12		6
	22	26/0.12		6
	20	42/0.12		6
3	26	10/0.12		6
	24	19/0.12		6
	22	26/0.12		6
	20	42/0.12		6
