DMX LIGHTING CABLE color guitar cable

  DMX LIGHTING CABLE color guitar cable       Guitar Cable   The Guitar is a music instrument which sound frequency very closed to the human voice.How to show out a clean and original voice is all cable manufacturers trying to pursue for breakthrough. The cable is particularly designed for traditional lighting color changer Providing less than DC48V, can be used on 2C power supply up to 10A DC48V And available to transmit DMX-512/RS-485 one pair cable Can supply traditional lighting color changer with good operation environment Each color changer 30W can move 14pcs. @DC48V  8pcs. @DC24V  4pcs. @DC12V Supply different sorts of electric products,together in producing&assembling

ITEM NO.	3071100011
JACKET COLOR	GREY
CONDUCTOR.	DC POWER: (41/0.16+PVC2.3)*2C  DMX: [7/0.20TC+PVC1.5]*2C
JACKET OD.	7.0mm
WIRE INFORMATION	[7/0.20TC+PVC1.5]*2C+AL+DW7/0.20TC+(41/0.16+PVC2.3)*2C+PVC7.0
MAIN CONDUCTOR AWG	24AWG 0.22mm^2 /  18AWG 0.823mm^2

ELECTRICAL PERFORMANCE

Cond.D.C.R ohm/1Km	DMX: 23.06 / POWER: 90.76
Shield D.C.R. ohm/1Km	DMX: 90.76
Nom.Cap.(pF/m)between conductors.	DMX: 59.94

          Packing & Shipping           Packing length : 40m/roll ,60m/roll ,91.4m/roll 100m/roll , 200m/roll , 300m/roll ; 305m/roll   Inner packing : plastic cover / wooden drum / paper drum ;   Outer packing : 2/4/ 6 roll / carton box ;   Other packing according to customers’ request !

ITEM NAME	MICROPHONE CABLE
CONDUCTOR	CCS/CCA/PURE COPPER/OFC
SPECIFICATION	AS REQUIRED
LENGTH(M)	AS REQUIRED
PACKING	COIL / PLASTIC SPOOL

      Item No.:A104060.128mesh
Conductor:Pure Copper
Specification:40×0.10×2C
Diameter:0.10,Strands:40,Cores:2
Jacket:Transparent
Length:100m

No. of core	Conductor construction		Braid	Outer Diameter (MM)
	AWG	Inner core No./mm
1	26	10/0.12	48/0.12 64/0.12 96/0.12 or as required	5.8
	24	19/0.12		5.8
	22	26/0.12		5.8
	20	42/0.12		5.8
2	26	10/0.12		6
	24	19/0.12		6
	22	26/0.12		6
	20	42/0.12		6
3	26	10/0.12		6
	24	19/0.12		6
	22	26/0.12		6
	20	42/0.12		6
