   EXTRAFLEX audio and control 22 AWG 2 pair individually shielded cable
  Specifications
Product Line:   22-2P-SHEX
Description 2 pair 22 AWG stranded, twisted, and individually shielded cable NEC type CMR and CEC type CMG FT4. Product manufactured compliant to the requirements of UL444 for installations and applications in accordance with NEC articles 725 and 800.
Conductor 22 AWG
16-strand annealed bare copper conductors
Diameter: 0.029" | 0.74mm
Electrical DC resistance: 16.61 Ω / 1000’ | 54.48 Ω/KM
Mutual capacitance: 35.74 pF/FT | 117.23 pF/M
Impedance: 56 Ohm
Velocity of Propagation: 55%
Voltage rating: 300V
Maximum current: 2.3A@25°C
Insulation Polyvinyl chloride
Wall thickness: 0.015" | 0.38mm
Diameter: 0.059" | 1.50mm
Regulatory NEC: CM 75°C
CEC: CMG FT4 60°C
EU RoHS-2 2011/65/EU Compliant
Color Code Pair 1: Red, Black
Pair 2: White, Black
Packages Reel: 1000’ | 305M
Weight: 38 Lbs/1000’ | 57 Kg/KM
Assembly Pair lay length: 2.25" | 60mm
5.3 twists per foot | 16.7 twists per meter
2 Shielded pairs cabled on a common axis
Installation Pull Tension: 31 Lbs | 138 N
Bend radius: 2.60" | 66mm unloaded
Bend radius: 5.20" | 132mm loaded
Construct 100% Paper tape binder
Ripcord under jacket
Applications General purpose line level balanced audio
General purpose low voltage control and RS-232C signaling
Shield 100% aluminum/mylar tape foil in
22 AWG 7-strand tinned copper drain
Performance Assuming 600 ohm source impedance:
Line level balanced audio 200 feet
Jacket Pressure extruded polyvinyl chloride
Colors: Pink, Yellow, Purple
Wall thickness: 0.050" | 1.27mm
Diameter: 0.260" | 6.60mm
Final Outside Diameter (inches) 0.26
