Databus Foundation Fieldbus cable Type

A single pair 22AWG Bi-Directional digital Databus Foundation Fieldbus cable for type B applications (31.25 KBits/sec).

The FS Cables Databus Foundation Fieldbus Type B cable is available in PVC, LSHF and SWA versions. Technical Information

Voltage: Operating Temperature: Velocity of Propagation: Nominal Impedance: UL Style: Conductor Resistance:	300V +75°C 66% 150 Ohms 2493 56.0Ω/km @ 20°C
Nominal Attenuation:	MHz 0.01 0.10 0.50 1.00	dB/100m 0.39 0.66 2.99 4.53

Voltage:

Operating Temperature:

Velocity of Propagation:

Nominal Impedance:

UL Style:

Conductor Resistance:

300V

+75°C

66%

150 Ohms

2493

56.0Ω/km @ 20°C

Nominal Attenuation:

MHz

0.01
0.10
0.50
1.00

dB/100m

0.39
0.66
2.99
4.53

Cable Construction Tinned copper conductors 22(7)AWG 0.34mm², polyolefin insulation, aluminium/polyester foil screen, tinned copper drain wire (22AWG) PVC sheath on standard cables.
