China waterproof best Color consistency low light fades outdoor light box signs 3 chips SMD 5050 injection LED module

Specifications The best Color consistency in LED light industry

High brightness

Easy Installation

Totally waterproof

Friendly environment

Specifications 1.With famous chip,
2.high brightness,
3.low light fades,
4.no shadow.     Product Applications: China SMD LED Modules with big light angle,no shadow,low light fades,easy to install and free maintenance;widely used in three-dimensional light words,restaurant, hospital, grocery or casino.     Features:
·Highest Brightness With famous chip,high brightness,low light fades,no shadow.
·Easy Installation
China LED Modules can be easily installed with 3M double-sided sticking tape.   ·Life Span
China LED Modules have a life time of more than 50,000 hours.
·Totally waterproof
With IP65 protection degree, LED Modules can operate normally in cloudy, rainy, desert, and snowy weather conditions or pool. The LED is totally covered by resin.
·Friendly environment
Pb free. With SGS CE/RoHS certificates, Waterproof LED Modules are up to 60% more energy efficient than neon.
·Safe Application     Low voltage DC12V, safety and stable. Free maintenance           Technical data:

Item No.	YL6820F-3W5050	YL6820F-3B5050	YL6820F-3G5050	YL6820F-3Y5050	YL6820F-3R5050
Size	L68mm*W20mm*H4.8mm
LED Quantity	3PCS  LED 5050
Input Voltage	DC Input 12V
View Angle	120 Deg.
Current	60mA	60mA	60mA	60mA	60mA
Power	0.72W	0.72W	0.72W	0.72W	0.72W
Luminance	52LM	9.4LM	36.3LM	13.4LM	16.3LM
Color	White 3000-10000K	Blue	Green	Yellow	Red
Connector	UL 1007 20# Gray White Wire   Length  100mm Gray Anode White Cathode
Group	20PCS
Max. Group	≤20PCS
Base	Beige PVC
Life	50 000 Hours
Ambient Temperature	-40°C- 60°C
Warranty	24 Months
Weight	13.7g/PC
IP Grade	IP67
