solar battery lifepo4 lithium ion battery 12V20Ah for lighting
  • solar battery lifepo4 lithium ion battery 12V20Ah for lighting
solar battery lifepo4 lithium ion battery 12V20Ah for lighting

solar battery lifepo4 lithium ion battery 12V20Ah for lighting

Delivery Time:
7 Days
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: Guangdong, China (Mainland)
Product Description
Product Description
solar battery lifepo4 lithium ion battery 12V20Ah for lighting    O'CELL 12V20Ah Solar Battery Pack with SLA Case Usage Notes: Our 12V20AH module, with nominal voltage of 12V and capacity of 20Ah is assembled with high power LiFePo4 cells.It can be used individually and can be connected in serial or parallel to achieve given voltage and capacity.   Features: a. Extremely safe and stable chemistry: PCB and/or BMS built inside to balance protect the battery. b. Long life-cycle: Can be circularly used, best can up to 2000 times recycles, 8 times of Lead acid battery. c. Lighter weight, with the best power-to-weight ratio: 1/3 of Lead acid battery weight. d. Good performance at high temperature and high temperature resistance e. Low self-discharge rate, less than 3% monthly. f.  No memory effects and highly efficient charge. g. Environment friendly: Clean and Green energy poses no pollution on our environment.

Item

Unit

Specifications

Nominal Capacity

Ah

20.0

Nominal Voltage

Voltage

12.0

DimensionH×W×L

mm

181×76×166mm

Weight

kg

2.55

Charge Cut-off Voltage

Voltage

14.6

Discharge Cut-off Voltage

Voltage

10.0

Charge current

Amps

10.0

Rated Discharging Amperage

Amps

25.0

Standard Discharging Amperage

Amps

25.0

Internal Resistance

<15 mΩ

Working Temperature (Charging)

oC

0oC--55oC

Working Temperature (Discharging)

oC

-20oC--70oC

Relative Humidity

N/A

45%--75%RH

Life Cycle(2C,80%DOD)



1000

Life Cycle(1C,80%DOD)



2000

Warranty

Year

1
