Infrared Human Movement Sensor Module SB6001

PIR infrared radial sensor Module  SB0061   Motion detector module uses a motion detector IC and PCB mounted Fresnel lens.
Item: SB0061
General
SB0061 is a pyroelectric sensor module which developed for human body detection. A PIR detector combined
with a fresnel lens are mounted on a compact size PCB together with an analog IC, SB0061, and limited
components to form the module. High level output of variable width is provided.
Features and Electrical Specification
Compact size (24 x 32 mm)
Supply current: DC5V-20V(can design DC3V-24V)
Current drain :< 50uA
Voltage Output: High/Low level signal:3.3V
TTL output: TTL output can be directly connected to micro-controller or logic device
High sensitivity
Delay time:5s-18 minutes(as customer requirement)
Operation Temperature: -15°C -70°C
Infrared sensor: dual element, low noise, high sensitivity
Light sensor: CdS photocell (can be add as customer requirement)
