Leeman P4 led display video screen indoor full color

Specification data sheet     Super Slim LightWeight Indoor Rental HD SMD RGB LED Video Wall Screen Panel   Model Number: P1.875/P2/P2.5/P3/P3.75/P3.91/P4/P4.615/P4.81/P5/P5.2/P5.92/P6/P6.944/P7.62/P8.925/P10/P10.41/P12.5   Die Casting Aluminum Rental Cabinet dimension:  480mm x 480mm 500mm x 500mm 512mm x 512mm 576mm x 576mm 640mm x 640mm 768mm x 768mm 800mm x 800mm 960mm x 960mm   Features: 1.Ultra-thin & ultra-light 2.Die casted AL cabinets, high precision with seamless splicing 3.Standard cabinet size: 500x500mm, convenient for area calculation 4.Highly effective & quick for transportation and screen assembling 5.SMD black light, wider viewing angle, high-contrast(5000:1),soft image 6.Special buckles structural connection between the cabinets,don’t need other tools 7.Cabinets are in common use for standard modules,shorten production cycl   Main Advantages: 1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.   Ultra-thin & Lightweight Die-casting Aluminum Rental LED Video Wall series

Pitch/mm	P3	P4	P5	P6
Module size/mm	192x96	128x128	160x160	192x96
Density of pixel/(dots/m2)	111111	62500	40,000	27,777
Pixel composition	SMD 3 in 1	SMD 3 in 1	SMD 3 in 1	SMD 3 in 1
Led encapsulation	SMD2020 Black Lamps	SMD2020	SMD3528	SMD3528
		Black Lamps	White Lamps	White Lamps
Resolution of module	63x32	32X32	32X32	32X16
Optimum viewing distance	3-10m	4-15m	6-16m	7.5-20m
View angle / °	140H,120V	140H,120V	140 H,120 V	140 H,120 V
Max power consumption/W/M2	1200	1,000	1,000	900
Size of cabinet/mm	576x576	512X512	640X640	768X768
Resolution of cabinet	192x192	128X128	128X128	128x128
Driving method	1/16 scan constant current	1/16 scan constant current	1/8 scan constant current	1/8 scan constant current
Refresh rate Hz/S	≥600	≥600	≥600	≥600
Luminance of white balance	≥1500 nits	≥1500 nits	≥1500 nits	≥1500 nits
Thickness	110mm
Operation of Environmental Temperature/°C	below 30  to  above 50
Working voltage	110-220 VAC/+/- 10%
Grey scale/color	displaying colors≥16.7M(synchronized)
Brightness adjustment	4096 levels of each color(manually),100 levels of each color(automatically)
Input signal	RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system	linsn(sending card,receiving cards and Hubs)
Average of non-failure life	>50,00h
Life span	>100,000h
Functionless  dot rate	<0.0001

    Indoor and outdoor die-casting rental aluminum cabinet:   1) Lightweight
2) Seamless connection
3) Ultra thin
4) Easy to maintain
5) Easy to install 6) Noiseless
7) Ghost Cancelling
8) High refresh rate
9) Low brightness and high gray scale
10) Low power consumption           Production process         Successful project cases for study
