p6 rgb smd 3 in 1 led display Leeman P6.25 SMD indoor red color led module

p6 rgb smd 3 in 1 led display Leeman P6.25 SMD indoor red color led module

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

Price is just P10 Outdoor RGB LED Module dimension 160mm x 160mm, resolution 16x16 pixels. If you want other size 160mm x 320mm or 320mm x 320mm, please contact us before buying!!! Connector Power Cable Plug 5V / Screws Fixed

Technical parameter
Unit board	Pixel pitch	10mm
	Module size	*160mm160mm**
	Resolution of module	16*16dots
	Density of pixel	10000dots/m2
	Pixel configuration	LED346 1R1G1B
Main Technical parameter	Red wavelength	625±2nm
	Green wavelength	525±2nm
	Blue wavelength	470±2nm
	Colors	16777216
	Best viewing distance	8-160m
	Horizontal/Vertical Viewing angle	120 degree/60 degree
	Gray scale	16bits per color
	Color temperature	6500k
	Brightness	More than 7500cd/sqm
	IP grade	Front :IP67 back: IP65
	Frame frequency	60HZ
	Refresh frequency	≥3500HZ
	Control method	Synchronization/Asynchronization
	Drive method	1/4 Scan
	Temperature	Storage:-30°C-+85°C
	Temperature	Working:-20°C-+65°C
	Operating ambient humidity	10%—95%RH
	Earth leakage current	< 2mA
	Defects rate.	≤0.00001(Led display line standard<0.0001)
	Flatness	Tolerance of interpixel≤0.3mm
	Flatness	Tolerance of modules clearance≤0.6mm
	MTBF	More than 10,000 hours
	Life span	More than 100,000hours
Power	Operating voltage	AC110V/220V±10%
	Maximum/Average power consumption	800/350w/m2
	Current	≤20mA(single LED)
	Power switch	Automatic switch
Control system	CPU	Pentium4 or above
	Signal Input	Composite ,S-video,Component,VGA,DVI,HDMI,SDI,HD_SDI,etc
	Controlling system	main controller card+optical fiber transmission
	Control method	Asynchronization
	Systems operating platforms	WinXP,Win2000,Vista, Win7, Win8 etc.
Softer ware	LED media player
