p20 outdoor led display/ led display board p10 led curtain display aluminum cabinet led display

Specifications 1. High brightness 12000nits

2. Outdoor waterproof IP65

3. CE ROHS ETL SGS SAA Fcc UL

4. Guarantee 5 years

5. Good effect

p20 outdoor led display/ led display board p10 led curtain display aluminum cabinet led display  Leeman P20 Outdoor LED Screen: Stable performance, wide applicability, high brightness, high protection grade.
1.high temperature resistant and aging resistant PC materials are applied in the modules to get rid of the mosaic problem even after long time use.
2.High brightness enables longer viewing distance and ensures the spectators far from the screen can still enjoy what is shown, even under direct sunlight.
3.The cabinets, featuring great moisture and corrosion proofing, enable themselves to work in all weather conditions.

Model	SINO-P20
Pixel pitch (mm)	20
Cabinet size (mm)	1280*1024
Brightness (nit)	7000
Module size (mm)	320*160
Pixel configuration (R,G,B)	2,1,1
Pixel matrix per module (dot)	16*8
Pixel (dot/s.q.m)	2500
Viewing distance (Min) (m)	16
Gray scale (level)	4096
Refresh frequency (Hz)	1200
Input power (max/avg)	1350/452
Viewing angle-H (deg.)	120 (+60/-60)
Viewing angle-V (deg.)	60 (+30/-30)
Blind spot rate	<1/10000
Color temperature (K)	6500
Ingress protection (front/rear)	IP65/IP54
Input voltage (AC)	110 ~ 240
Input power frequency (Hz)	50 or 60
Signal input format (with video processor)	AV, S-Video, VGA, DVI, YPbPr,  HDMI, SDI
Operating system	Windows (2000/XP/Vista)
Control distance	CAT5 cable:<100 m; Single fiber:<10 km

    Leeman Project Case In Middle East
