Leeman P5,P6,P7,P8 and P10 indoor and outdoor rental led screen /led video display panel

Leeman P5,P6,P7,P8 and P10 indoor and outdoor rental led screen /led video display panel

Get Latest Price

Payment Type:: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal, Cr

Min. Order:: 1 Square

Min. Order:: 1 Square

Delivery Time:: 3 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)
Supply Ability:	10000 Square Meter/Square Meters per Month
Payment Type:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,Paypal, Cr

Product Description

Specifications 1. High brightness 2000nits

2. High Resolution 27777

3. CE ROHS ETL SGS SAA Fcc UL

4. Low power consumption

5. High quality

Description:
* Wide viewing angles
* Seamless and lightweight
* Dynamic scanning with truer, more stable pictures( no flickering)
* Modular design for easy installation and maintenance
* Consistent uniformity over time
* Brilliant colors, breathtaking grayscales
* Operating software compatible with widely available software
* Remove the tools, improve the serviceability

Applications:
Entertainment complexes, Churches, Restaurants, Showrooms, Casinos, Convenience Stores, Banking, Government facilities, Theatres and Retail outlets etc.

Pixel pitch	6 mm	6 mm	6 mm
Type	SMD3528 1R1G1B	SMD3528 1R1G1B	SMD3528 1R1G1B
Environment	Indoor	Indoor	Indoor
Resolution	27777dots	27777dots	27777dots
Module resolution	32x16 dots	64x32 dots	64x32 dots
Module size	192 mm*96mm	384 mm*192mm	384 mm*192mm
Cabinet resolution	96*96 dots	128*128 dots	128*128 dots
Cabinet size	576mm x 576 mm	768mm x 768 mm	768mm x 768 mm
Cabinet material	Aluminum	Aluminum	Aluminum
View distance	4meters-60meters	4meters-60meters	4meters-60meters
View angle	H160°V120°	H160°V120°	H160°V120°
Refresh rate	>3200 HZ	>3200 HZ	>3200 HZ
Maximum powerconsumption	650W/M ²	500W/M ²	400W/M ²
Average power consumption	300W/ M²	250W/ M²	200W/ M²
Scan mode	1/8 constant current	1/8 constant current	1/16 constant current
Brightness	2200 CD/ M ²	2200 CD/ M ²	2200 CD/ M ²
Power supply demand	AC220V/110V
Drive voltage	5V/40A
Life span	100,000hours
Working Temperature	-40°C~65°C
Working Humidity	10%RH~90%RH
Gray scale	4096
Operating platform	Windows 7/8, Windows 2000, XP, and Vista OS
Running Files	Text, Animation, Picture, Video and etc
Ingress Protection	IP45 / IP65

Leeman Project Case For Study
