indoor p7.62 digital led video xxx display p10 led module 320 160 indoor led display screen p6 video

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

Specifications 1. High brightness 2000nits

2. High Resolution 17222

3. CE ROHS ETL SGS SAA Fcc UL

4. Low power consumption

5. AC110V-240V

indoor p7.62 digital led video xxx display p10 led module 320 160 indoor led display screen p6 video P3 P4 P5 P6 P7.62 P8 P10 Indoor & outdoor led display screen

Item	Parameter	Item	Parameter
Pixel Pitch(mm)	7.62mm	Red wavelength	625nm±5nm
Resolution(W×H)	17222dots/m²	Green wavelength	525nm±2.5nm
Pixel Configuration	1Red, 1Green, 1Blue	Blue wavelength	475nm±2.5nm
Module dimension	W244mmxH122mm	optimum viewing distance	8m
Module Resolution(W×H)	32dots×16dots	Working environment	Temp:-20~+60 Humidity:10%~90%
Cabinet dimension	W976mmxH732mm	Life time	100000 hours
Cabinet resolution	W128dotsxH96dots	Gray scale	10bit/color
Cabinet weight	15kg/m²	Color display	1.07 billion
Max power W/m²	800W/m²	Blind LED lamp rate	<0.00001
Drive mode	Constant current 1/8 scan	Waterproof class	None
Cabinet Material	Steel/Aluminum	Warranty	5 Year
LED assembly type	SMD 3in 1	MTBF	5000hours
Refresh frequency	≥1200 HZ	Input voltage	AC110/AC220
