indoor full color led video screen with transparent display module

Specifications flexible installation led curtain

Flexible

High transparent

CE ROHS

2 years warranty

flexible installation led curtain ---(gDOT) Ultrathin, lightweight,  Thickness ≤32mm, 5kg per/pixel roll. Flexible and soft for quick installation. Uniquely dual side visual display. Multiple funtions: Display, lighting, decoration...etc. Various pixel pitch available: P55, P80, P110, P160 and customize acceptable. Waterproof IP43/IP65, indoor/outdoor. For rental market and fixed installation. Certificate: CE( TUV), RoHS      Application:   TV shows, live shows, events background display Party, stage lighting Hotel, disco, bars, night club ceiling and floor decoration Architectures exterior lighting decoration   Certificate: CE( TUV), RoHS    Application:     TV shows, live shows, events background display Party, stage lighting Hotel, disco, bars, night club ceiling and floor decoration Architectures exterior lighting decoration.   Specification:

Model	gDOT-55	gDOT-55H	gDOT-80	gDOT-80H
Pixel Pitch	55mm	55mm	80mm	80mm
Pixel Density	330/sq meter	330x2/sq meter	156/sq meter	156x2/sq meter
Brightness	900 nits	900 nits	420 nits	420 nits
Pixel Surface	SINGLE	DUAL	SINGLE	DUAL
Max Power Consumption	≤150W	≤300W	≤70W	≤140W
Ave Power Consumption	≤75W	≤150W	≤35W	≤70W
General Parameters
Pixel Composition	RGB 3 IN 1 SMD
Viewing Angles	H120° V120°
Refresh Rate	≥1000Hz
Gray Scale	12 bits
Color Space	68 Billion
Control System	PC based dynamic capture&mapping
Operating Life	More than 50,000 hours
Power Supply	AC90-260V, 50-60Hz, Meanwell
Protection	IP43/IP65 on pixel strings, IP54 on signal distributor and power box
Working Environment	Temperature -20-50°C, humidity 10-90%RH
