P8 Indoor Stage LED Billboard

Specifications 1.stage led billboard

2.Excellent visual effect

3.CE& RHOS certification

4.High brightness

5. Stable capability

1.The specification of the Stage LED Billboard

Specification of P8 stadium perimeter
	Pixel
1	Pixel Pitch	8 mm
2	Pixel Density	15625 Pixels / m²
3	Pixel Composition	SMD3528 3in1
	Module
4	Module Dimension (H x V)	256mm x128mm
5	Module Resolution (H x V)	32Pixels x16Pixels
	Cabinet
6	Cabinet Dimension (H x V)	768mm x 512mm
7	Cabinet Resolution (H x V)	96 Pixels x 64Pixels
	Entire Screen
8	Maximum Brightness	1700 cd/m²
9	Optimal Viewing Distance	>8m
10	Maximum Power Consumption	800  Watts/m²
11	Scan Mode	1/8scan; Constant Current
12	Refresh Frequency	300HZ-9600HZ,
13	LED Life-span	50,000 - 100,000 Hours
14	Ambient Operating Temperature	-20°C ~ +60°C

  2. The advantage of P8 Stage LED Billboard   1).Each pixel is made of one RGB SMD LED 2). As RGB SMD LED ,more colorful,more vivid. 3). Viewing angle is available up to 160°, the showing contents aren't distorted. 4). Integrated and modularized design, reasonable layout, is the best advantage for heat dissipation. 5). Simple and light frame is easy for installation, can be customized according to client's demands.   3. Module of SMD Stage LED Billboard                4. Aging test    5. We have these certificates bellow:
