high quality HD indoor P5 led module / P5 clear x video led display made in China factory

High quality HD indoor P5 led module / P5 clear x video led display made in China   1.Features                                                                                                                         1.  2015 trends High resolution and  relateively low price compare to indoor P2.5 / P3 / P4.Especially for large screen size.   2.  Light weight & super slim Cabinet made of aluminium alloy material,thickness is only 80mm,640mm*640mm cabinets weight only 12kgs/pc.It's perfectly for rental use.save install space / easy assemble / dismantle.   3.  WIDE-viewing angle SMD has good viewing effect, when viewers are closed to screen..Also SMD has wider view angle up to 140°from both vertical and Horizontal.   2.parameter table

Item	Parameter
Pixel Pitch	5 mm
Pixel Density	40000dots/sqm
Pixel Configuration	1R1G1B   SMD 3inl
Module Size	32mm*160mm /160mm*160mm
Module Resolution	32*32 dots



Cabinet Size	640mm*640mm
Brightness adjustment	64 level automatic or manual
Cabinet Material	Aluminum or SPCC
Viewing Distance	>4m
Viewing Angle (Horizontal Axis)	140°
Viewing Angle (Vertical Axis)	140°
Refresh Rate	>800Hz
Grey Scale	≥14bits
Frame Frequency	--
Brightness	≥ 2200CD/M2
Power Consumption	Max:≤900w/sq.m ; Averange: ≤300w/sq.m
Average Power Consumption	--
Driving Mode	1/16 Scan Constant Current
Driving IC	Brand MBI/JXI/TLC etc.
Input Volage	AC110V/220V± 10%, 50/60Hz
Control System	Nova/LINSN/Mooncell etc.
Defects Rate	<0.0001
MTBF	≥10000Hrs
LED Lifespan	≥10,0000 hours
Operating System	Windows98/me/2000/NT/XP
IP Grade	IP43
Input Voltage	AC110V\AC220V±10%50-60HZ
Input Signal	DVI( if with Video Processor, more input signal)
Signal Interface	DVI with USB
Working environment	Celsius Degree:–20°C-+60°C; humidity:10%-90%RH

   3.Ref photo                                                                                                                           Rental - Hanging installation      Fixed - Base type / Inlaid type / Hang type / wall mounted type the most popular installation way.    4.FAQ                                                                                                           (1)How much does a LED giant screen costs The final cost of a LED billboard depends on two main factors: The resolution, The size of the maxi screen   (2)What are the MINIMUM and MAXIMUM viewing distances of a LED giant screen?
The minimum and maximum viewing distances of a LED screen are measured  depending on two fundamental characteristics of the screen: the pixel pitch and the screen’s dimension.     5.Company information                                                                                                       Pre-name:Xinhongxiang Optoelectronics (Shenzhen)Co.,Ltd Re-name:Shenzhen Besdled Co.,Ltd Led encapsulation since 1996s Coving 20,000 square meters.     6.Brazil expo music fair                                                                                                          BESD Contact person christian li.
