HD indoor led screen panel, p4, p5, p6 high brightness stage background led display screen, led video display panel

HD indoor led screen panel, p4, p5, p6 high brightness stage background led display screen, led video display panel introduction:   HD led screen Features:   1. The first level LED chip from Taiwan Epistar.   2. With pure golden wire connection in LED.   3. Grand A row material for module frame and mask.   4. 4 layers PCB and copper plating thickness > 18mil.   5. Ag alloy solder paster to ensure good soldering on PCB.   6. Stainless steel screws when assembly.   7. Die-casting aluminium material cabinet ensures perfect flatness and no gap between cabinets.   8. Disassembly and assembly are quick and easy.   9. Three years warranty.    Indoor P6 led screen panel Technical Specifications:

ITEMS	Indoor full color led screen panel
Module	Pixel Pitch	6mm
	Pixel Density	27,777dots/m2
	Led Lamp Type	SMD 3 IN 1
	Led encapsulation	SMD3528
	Led Configuration	1R1B1G
	Module Size	192×192mm
	Module Resolution	32×32
	Scan Mode	1/8 scan, 1/16 scan
	Drive Mode	Constant Current
Cabinet	Cabinet Size	768×768mm, 576mmx576mm
	Cabinet Resolution	128×128
	Module Quantity	32pcs
	Cabinet Weight	45kg/m2
Display	Brightness	≥2000cd/m2
	Contrast Ratio	≥2000:1
	Viewing Angles	140°(H)/140°(V)
	Min. Viewing Distance	5m
	Gray Scale	RGB/8192/14bits
	Colors	68.7 billion
Power Supply	Max Power Consumption	850w/m2
	Working Voltage	AC 90 to 260V,50 to 60Hz
Control System	Frame Changing Rate	60 to 85Hz
	Refresh Rate	400 to 2000Hz
	Brightness Adjustment	0 to 100%
	Ganma Correction	(-0.5 to 5.0)
	Color Temperature	3000 to 9300K
	Brightness Correction Mode	By Pixel,Module,Cabinet Correction
	Data input Source	AV,S-Videom,VGI,DVI,HDMI,SDI,DP
	Control Method	Synchronization with computer
	Data Transmission Distance	100m by UTP CAT5;500m by Multi Optic Fiber;10km by Single Optic Fiber
	Operation Environment	Windows(2000,XP,Vista,7)
Reliability	Storage Temperature	(-40 to 85)centi degree
	Working Temperature	(-20 to 50)centi degree
	Working Humidity	10% to 90%
	Lifespan	100,000Hrs
	MTBF	5000Hrs
	IP Rating	IP43
	Blind Spot Rate	≤0.01%

  Pictures of P6 led screen panel:               Product P6 led screen panel features: 1. SMD3-in-1 technology is used for indoor LED Display 2. Wide view angle: 140 in horizontal and 140 in vertical. 3. Special design and advanced SMT technology improves the heat dissipation. 4, With high refresh rate controller, guarantee that no scan line when taking photos. 5. Regular shape and special shape(such as curve, round) can be designed. 6. Easy for assembling and connection with the connector added. 7, High color uniformity and clear image can bring you a vivid audio visual effect. 8. Both front access and rear access are available. 9. Items: BESD-IFP4, BESD-IFP5, BESD-IFP6, BESD-IFP7.62, BESD-IFP8, BESD-IFP10 10. Widely used in meeting room, lobby of hotel, cinema, shopping mall and station, airport, studio, stadium etc.     Company introduction and certifications:         Our best quotation will be offered to you once got your enquiry. Thanks!
