shenzhen manufacturer P8 waterproof led display, stadium led board, P8 waterproof xxx video led display board

P8 waterproof led display, stadium led board, P8 waterproof stadium led display board   Sports perimeter led display series( P8, P110, P12, P16, P20, P25 ).   Main features, Function Introduction   1,Designed according to the standards of the country of the client. 2,Usage: Outdoor/Indoor Sports perimeter, football stadium, basketball stadium, soccer stadium etc. 3,Waterproof: IP 65 front, IP 43 rear. The system can stand all weather condition. 4,High luminance and uniformity, wide view angle and various content show. 5,Items:BESD-OFP10,BESD-OFP12,BESD-OFP12.5,BESD-OFP16,BESD-OFP20,BESD-OFP25 etc.   P8 outdoor SMD LED Module     Parameter table

Model	BESD-OFP8
Pixel Pitch	8mm
Pixel configuration	1R1G1B
View angle	140°/140°
Pixel density	15,625dots/sqm
Module size	256*128mm
Module Resolution	32*16dots
LED encapsulation	SMD 3528
Refresh rates	>=800 HZ
Driving Method	1/8 scan , constant current
Max power consumption	750W/sqm
Brightness	>=6,000CD/sqm
Display Function	Graphics, Animation, and video
Working voltage	110V~±15% or 230V~±15%
Working temp	-20°C to +60°C
Optimum viewing distance	>7m
Working Humidity	35% ~ 85%
LED parameters	R:625nm±5.0nm, IV:400-500mcd
	G:525nm±2.5nm,IV:800-2,200mcd
	B:470nm±2.5nm,IV:350-450mcd
MTBF	>5,000hous
Gray Level	RGB/8192/14bit
Life span	>100,000hours

                                                                                            Stadium led board     Construction introduction 1,Special brackets installed at the backside of the cabinet is used for adjusting the gradient of the display, meanwhile it is easy to take down .  2,Strong side lockers keep two adjacent cabinets tight.  3,With fold and unfold block and tackle designed, easy for mounting and dismantling.  4,Soft, replaceable and impact-resistant covers protect leds from damaged and players from injury.   Soft Shelter 1. Protect the player from injury when the player hits the display.   2. Protect LEDs from harm when the ball impacts the display. 3. Easily replace. 4. Soft pad on the top of cabinet, and easily to be removed when the cabinets will be assembled to video wall.   Three standards 1. Can be adjusted to different angles. 2. Easy to fold the two stands up to the flute, saving much space of store. 3. Special design can avoid the cabinet falling forward.   More unique designs in details 1. Power & net cable connector 2. High IP grade 3. Power cable connector with cover 4. Easily to plug in and out   Control system        Company Profile From 1996 to 2010, Xinhongxiang Optoelectronics (shenzhen) Co.,Ltd, mainly involved in LED encapsulation and LED Display.   Since 2010, owe to enlarge the company scale and build up self-owned brand, Rename to Shenzhen BESDLED Co., LTD, business involved in indoor and outdoor LED Encapsulation, LED Display and LED Lighting Products. Comparing with many of LED Manufactures, BESDLED owns the following advantages to be your best choice for long term cooperation partner.   1. Fully automatic production lines BESDLED owns the entire LED manufacturing line, encapsulate original Semiconductor to LED chip, then assemble to led display and led lighting products.   2. Advanced production equipment SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP led, Spectrum and Color Separation Machine, LED oven, Wave solder, Reflow soldering, Spectrum electronic and color tester, temperature and humidity programmable tester, luminance meter etc. are equipped for our LED Product production.   3. Many certifications approved to clear up the trade barriers CE, FCC, UL, RoHS, CCC,ISO9001: 2000 etc are obtained.   4. Strong R&D Team BESDLED absorbs many talents, with more than 500 staffs, and including more than 100 engineers and technician, which paves the way for R&D for new products and excellent sales service.       Our exhibition in Netherlands
